Technical Specifications
ORiNOCO
®
AP-9200R - Hardware Installation Guide 18
Wireless Protocol
Interfaces
Radio #2: 2.4 GHz
Products MCS Index Modulation Coding Rate
Data Rates (Mbps) Per Stream
20 MHz Channels 40 MHz Channels
800ns GI 400ns GI 800ns GI 400ns GI
AP-9200R 0 BPSK 1/2 6.5 7.2 13.5 15
1 QPSK 1/2 13 14.4 27 30
2 QPSK 3/4 19.5 21.7 40.5 45
3 16QAM 1/2 26 28.9 54 60
4 16QAM 3/4 39 43.3 81 90
5 64QAM 2/3 52 57.8 108 120
6 64QAM 3/4 58.5 65 121.5 135
7 64QAM 5/6 65 72.2 135 150
Note: Maximum Packet Size = 9000 Bytes (excluding one VLAN header, Ethernet header and FCS).
Category Specification
Wireless Protocol Radio #1: 802.11a/n/ac
Radio #2: 802.11b/g/n
Products Category Specification
AP-9200R
Wired Ethernet Auto MDI-X, auto configuration and fixed
speed/duplex configurations.
One auto MDI-X RJ45 Gigabit Ethernet Port
with PoE IN and Data.
