OFDM Modulation Rates
Given below are the OFDM modulation rates for the ORiNOCO
®
products:
949-00150 ETH-STP-50-CAP 50m outdoor, RJ45 terminated, UV Rated, STP Shielded CAT5e cable with
M20 and M25 cable gland
949-00175 ETH-STP-75-CAP 75m outdoor, RJ45 terminated, UV Rated, STP Shielded CAT5e cable with
M20 and M25 cable gland
949-00154 ETH-CAP-M25-25 Cable Feed Thru, M25 Cable Gland Connector for Edge and ORiNOCO®
9200R - 25 pack
949-00155 1000-UMK Outdoor Universal Mounting Kit for Edge and ORiNOCO® 9200R
949-00076 10000-UMK Outdoor Universal Mounting Kit for Tsunami® 800/10100 and outdoor
ORiNOCO® 9100
Radio #1: 5 GHz
Products MCS
Index
Modulation Coding
Rate
Data Rates (Mbps) Per Stream
20 MHz Channels 40 MHz Channels 80 MHz Channels
800ns GI 400ns GI 800nsGI 400ns GI 800ns GI 400ns GI
AP-9200R 0 BPSK 1/2 6.5 7.2 13.5 15 29.3 32.5
1 QPSK 1/2 13 14.4 27 30 58.5 65
2 QPSK 3/4 19.5 21.7 40.5 45 87.8 97.5
3 16QAM 1/2 26 28.9 54 60 117 130
4 16QAM 3/4 39 43.3 81 90 175.5 195
5 64QAM 2/3 52 57.8 108 120 234 260
6 64QAM 3/4 58.5 65 121.5 135 263.3 292.5
7 64QAM 5/6 65 72.2 135 150 292.5 325
8 256-QAM 3/4 78 86.7 162 180 351 390
9 256-QAM 5/6 N/A N/A 180 200 390 433.3
Note: Maximum Packet Size = 9000 Bytes (excluding one VLAN header, Ethernet header and FCS).
