Technical Specifications
Device Models
Accessories
Model Part
Number
Description
AP-9200R-US 903-00035 ORiNOCO
®
AP-9200R, MU-MIMO 4x4 w2, dual radio, connectorized outdoor
Access Point – US Power
AP-9200R-WD 903-00036 ORiNOCO
®
AP-9200R, MU-MIMO 4x4 w2, dual radio, connectorized outdoor
Access Point – WD Power
AP-9200R-JP 903-00040 ORiNOCO
®
AP-9200R, MU-MIMO 4x4 w2, dual radio, connectorized outdoor
Access Point – JP Power
AP-9200R-CN 903-00041 ORiNOCO
®
AP-9200R, MU-MIMO 4x4 w2, dual radio, connectorized outdoor
Access Point – CN Power
Part Numbers CAMCODE Accessories
76955 PA5-0823-DP 4.9 - 5.875 GHz, Dual Polarity, Slanted (±45º) or V/H, 23 dBi Panel Antenna
949-00019 PA5-0530-DP 4.9 - 6.1 GHz, Dual Polarity, Vertical and Horizontal, 30 dBi Panel Antenna
949-00011 SA5-6015-DP 4.9-6GHz, Dual Polarity,Vertical /Horizontal,16.5 dBi Sector Antenna - 60
degrees.Mounting kit Incd.
949-00012 SA5-9014-DP 4.9-5.95GHz, Dual Polarity,Vertical and Horizontal, 14dBi Sector Antenna- 90
degrees. Mounting kit Incd.
949-00027 PA2-1720-DP 2.3-2.7 GHz, Dual Polarity, Vertical & Horizantal, 20 dBi Panel Antenna
949-00152 CBL-240-6-RA 6 ft Low Loss Coaxial Antenna Cable, 0.240", Reverse Polarity SMA Male to
Right Angle N-Male
949-00153 SMA-CAP-50 SMA metal weatherproofing cap with O-ring (fit SMA and RP-SMA
connectors) - 50 pack
400-00036 GIG-POE-INJ-48VDC PoE Gigabit 48V DC Injector with terminal Jack
400-00002 GIG-POE-INJ-48VDC-T PoE Gigabit 48V DC Injector with terminal Jack - 25 pack
949-00140 ETH-POEINJ60-1G-VI Gigabit, 60W, PoE injector with RJ45, level VI Compliance
949-00144 ETH-POEINJ30-1G-VI-v2 Gigabit, 30W, passive PoE injector with RJ45, level VI Compliance
235-00001 ETH-SURGE-1G SURGE, GIGABIT SURGE PROTECTOR WITH SHIELDED RJ45
949-00125 ETH-STP-25-CAP 25m outdoor, RJ45 terminated, UV Rated, STP Shielded CAT5e cable with
M20 and M25 cable gland
