CX-Series Service Manual
TRIM PARTS
LATCH BACKSETS
ITEM
PART NUMBER
DESCRIPTION
B1
C01
-
0030A
2 3/4"
(Standard)
B2
C02
-
0030A
2 3/8”
Round Edge
B3*
C03
-
0030A
2 3/4” Drive
-
in
& No Faceplate
B4*
C04
-
0030A
2 3/8” Drive
-
in
B5*
C05
-
0030A
5”
B6*
C06
-
0030A
3 3/4”
*Special Order
LATCHES
Optional latch extensions
7
-
C
5” Backset
(70mm) latch + 57mm extension
tube for 5" (127mm) requirement
3 ¾” Backset
(60mm) latch + 35mm extension tube
for 3¾" (95mm) requirement
B1
B2
B3
B4
B5
B6
