CX-Series Service Manual
LOCK PARTS
B FUNCTION CHASSIS – STANDARD
ITEM
PART NUMBER
DESCRIPTION
1
C10
-
0040A
C
ontrol Key
2
A00
-
0001A
Removeable Core
3
C00
-
0001A
Exterior Lever
4 C00-0006B Exterior Trim
5
C00
-
0016A
Exterior Rose
6
C00
-
0012A
Chassis Plate
7
C00
-
0011A
Chassis Housing
8
C00
-
0041A
Through Hole Posts
9
C00
-
0018A
Exterior Backplate
10
C00
-
0021B
6
-
Pin Ribbon Cable
11
C00
-
0036A
Exterior Trim Screws
12 C00-0020A
Exterior Gasket
ITEM
PART NUMBER
DESCRIPTION
13
C01
-
0031A
Latch
14
C02
-
0030A
Strike Plate
15
C00
-
0019A
Interior Gasket
16
C00
-
0017A
Interior Backplate
17
C00
-
0037A
Interior Screws
18
C00
-
0015C
Interior Rose
19
C00
-
0007B
Interior Trim
20
Interior Trim Screws
21
C00
-
0005B
Battery Cover
22 C00-0038B Battery Cover Screw
(Standard or Security)
23
C00
-
0002A
Interior Lever
6
-
A
6
-
B
