CX-Series Service Manual
PROGRAMMABLE FUNCTIONS
Unlike standard locks, Proxess has just one SKU allowing any lock to be supplied and programmed into numerous lock
“functions” similar to standard locking functions shown in the chart below.
Name Similar ANSI #
Mech
Proxess Electronic Equivalent Function
Entrance F109 Enable toggle schedule and double present
credential to outside
reader to lock/unlock door
Storeroom F86 A valid credential should provide momentary
unlocking and allow entry by that user, with the
latch relocking in an administrator defined time
(usually 5
-
8 seconds)..
Office F82 A valid credential should provide momentary
unlocking and allow entry by that user, with the
latch relocking in an administrator defined time
(usually 5
-
8 seconds)..
Classroom no Lockdown F84 Enable toggle schedule and double present
credential to outside reader to lock/unlock doo
r.
Classroom w/Lockdown
(Intruder)
F110 Enable toggle schedule and double present
credential to outside reader to lock/unlock door.
Lockdown performed by gesture.
Classroom w/Holdback F85 Enable toggle schedule and double present
credential to outside reader to lock/unlock door.
(electronic equivalent to F84, because unlocked
door allows free entry). There is no Holdback.
Canadian Function Select toggle mode in the ACS and depress internal
button to toggle the lockset from
lock/unlock.
Patio F77 Select toggle mode in the ACS and depress internal
button to toggle the lockset from lock/unlock.
Secured Privacy
Select toggle mode in the ACS and depress internal
button to toggle the lockset from lock/unlock.
Hotel Guest Room F93 A valid credential should provide momentary
unlocking and allow entry by that user, with the
latch relocking in an administrator defined time (no
visual indicators)
Dormitory F90 Select toggle mode in the ACS and depress internal
button to
toggle the lockset from lock/unlock.
Service Station F92 Enable toggle schedule and double present
credential to outside reader to lock/unlock door.
Exit Latch
F89
Mechanical lockset
Privacy
F76
Mechanical lockset
Passage
F75
Mechanical lockset
