User Manual

TECH SPECS GENERAL
Model Name
VeCODER ULTRA-8 HDMI
SKU
0649070905732
Power
100-240 VAC 50/60 Hz, 60W max. 30W Typical IEC 60320-C14
Cooling
Dual internal cooling fans with Front inlet and Sides exhaust
Fan dB level
<20db Super Quiet Operation under normal conditions
Temperature/Humidity
+32 F° to +115 F° (0 C° to +46 C°) / 10% to 80% non-condensing
Vibration
NSTA 1A in carton
MTBF
55,000 hours
Compliance
FCC Class A, IEC60065, EN61000, CE, RoHS, RCM C-Tick
Enclosure Type
EMI Shielded Metal
Mounting
In-Rack Mounting with 19" Rack Ears adapters included, 1RU high
Enclosure Dimensions
1.72 in. (H) x 19 in. ( front external rack ear to ear dimension ) x 12.5 in. (D)
System Weight
12.47 lbs. (5.6 kg)
Carton Dimensions
(Individual)
4.25 in. (H) 30.875 in. W 14.015 in (D); 108 mm (H) 785 (mm) W 356 (mm) (D)
Shipping Weight
15.1 lbs. (6.85 kg)
Warranty
5 years
Reliability
Modular Cards for zero downtime 24/7 Operation
System Maintenance
Modular Design allows on-site replacement of any encoder processing board card without removing the
system from site
INSTALLATION
Remote Control
Via PC and provided Management Software
Simple Setup
Simple configuration via Login-Protected Web Interface
IPTV Networks
Built-In Multi-Gigabit IPTV Server to drive directly any LAN, WIFI, INTERNET, with M3U8, HLS, RTMP,
HTTP, UDP, RTSP
HDMI Inputs
Licensed HDMI inputs compatible to any HDMI Video source
Multi-Units
Multiple units can be used on the same network for more channels, by simply configuring different IP
Addresses per each machine
VIDEO INPUT
HDMI
8 ports of Licensed HDMI input - compatible to any HDMI Video Source up to 1080p resolution
HDMI Version
Compatible to any HDMI source including HDMI 2.0 ( Max input resolutions 1080p 60 )
EDID Control
Advanced EDID Auto control compatible with any HDMI Video source
AUTO Detection
Auto frame-rate input switching
CC Closed Caption
Digital In-HDMI CC video pass
Video Resolutions
480i / 480p / 576i / 576p / 720p / 1080i / 1080p ( AUTO EDID or Selectable SCALER per channel )
Sub Resolutions and PC Resolutions are also supported on both HDMI Inputs and the Target Encoding
Frames Ratio
1 to 60 FPS selectable stream by stream
Aspect Ratios
16:9 / 4:3 / Film mode detection (3:2 pull-down)
AUDIO INPUT
HDMI AUDIO
Any HDMI Embedded Digital Audio
COLOR BARS
TEST GENERATOR
Built-In Broadcast HD Test Pattern Generator for plug 'n play installations and input signal lost detection
VIDEO ENCODER
Encoder Video Profile
- Selectable per each HDMI / per each of the 4 Multi-rate sub stream
- MPEG4 H.264 base profile / main profile / high profile - any level
Encoding Mode
Interlace & Progressive encoding support
Video Processing
Extensive video pre-processing help get the best picture whatever the source
Processors Per Channel
Broadcast Encoder Chipsets for maximum Quality
Video Processing
Extensive video pre-processing including Noise reduction and Resolution changing
Encoding In-Out Latency
<50 milliseconds HDMI input to IP out in udp mode - Excluded player buffering
Traffic Shaping
Selectable Triple Motion Estimation Look-Ahead Statistical Variable Bitrate or Constant Bitrate
Video Encoding Data
Rates
VBR Variable, 64Kbps 15Mbps per channel
Color Profile
4:2:0 Broadcast Grade Sampling
GOP Size
15
PCR Precision
Broadcast-Grade Accuracy
AUDIO ENCODER
Channels
1 x stereo audio channel processing
