VeCOAX MicroMod 3 AV + HDMI RF Modulator Manual

COMBINING SERVICE PROVIDERS SIGNALS OR ATSC WITH YOUR

DEVICE

For Combining ATSC (Over the Air channels) you must find the frequencies that are used by your local

stations. This information can usually be found online by searching for, “(insert your local area) ATSC

frequency chart.” This typically shows all the Frequencies used in your area. Find the ones that are not

used and write those down. Set your device(s) to those unused frequencies. Test using your Test TV.

For combining with Cable Service provider, the same rules apply. You can contact the local service

provider of your basic cable to find the frequencies that they use and find the ones that are available

for you to use. If you wish to inject into a Digital Cable Converter box or STB(set-top box) most of the

time the service provider will include a channel you may broadcast onto or some providers require a

specific PIDs to be set which can be set in the ADVANCED OPTIONS MENU in order for the Set Top box

to be able to read the channel.

AUDIO ENCODING SETTINGS

The unit has three standards of Audio Encoding. Depending on your local and supported format per

TV you can set the following:

• AC3 – 2.1 Dolby Digital Audio US/Canada Standard for Broadcasting

• MPEG – MPEG 2 Layer II used in DVB-T EU Standard.

• ACC - Advanced Audio Coding or MPEG-4. Used in some ATSC broadcasts and ISDBT format.

Supported by Most TVs worldwide.
