Specifications

Specifications
Power 1100W
Speed 1st/2nd gear 0-1100/2800 rpm
Impacts/minute 1st/2nd gear 0-20000/56000
Max drill ¼ in masonry/steel/wood 24/16/45 mm
Torque 1st/2nd gear 65/22.5 Nm
Chuck clamping range 1.5-13 mm
Chuck thread 1/2”-20 UNF
Collar ¼ 43 mm
Weight 2.8 kg
PDP 24-2 EAQ-Plus
Includes: Keyless chuck "AutoLock", side-handle, drill
bit depth gauge, in a Systainer.
PDP 24-2 EAQ-Plus
629 506
in a Systainer
Top of the range model with
1100 Watts of pure power
Specifications
Power 1050W
Speed 1st/2nd gear 0-970/1750 rpm
Impacts/minute 1st/2nd gear 0-19400/35000
Max drill ¼ in masonry/steel/wood 32/25/35 mm
Crown borer ¼ concrete/brick 90/120 mm
Chuck clamping range 3-16 mm
Chuck thread 5/8”-16 UN 2A
Collar ¼ 57 mm
Weight 4.1 kg
PDP 32-2 EQ
Includes: Keyed chuck with clawed jaws and locking
device, telescopic side handle, drill bit depth gauge.
PDP 32-2 EQ
622 954
in a carton
Extremely powerful variable
speed hammer drill
• designed for heavy duty applications
- high torque motor and 2-speed
gearbox
• robust design with durable drive
spindle and spindle bearings
• variable speed to suit a range of
applications
• protects you from twist injury -
friction safety clutch
• forward/reverse rotation for driving
and removing fasteners
• precision-engineered locking keyed
chuck.
• extra power to do the really tough jobs
• 2-speed gearbox with variable speed to
suit a range of materials
• one-handed bit changes - keyless
chuck and automatic spindle lock
• built to last: with all-metal gearing,
alloy gearbox
• forward/reverse rotation for driving
and removing fasteners
• ergonomic rear handle and 360°
rotatable side handle
• well protected during transport in a
durable, handy Systainer
GDP 650 A (above, right)
Specifications GDP 320A/650A
Base plate 207 x 172 mm
Centering plate for diameter 8, 10, 12, 14, 16, 18,
20, 22, 24, 26 mm
Clamp, attachment collar dia. 57 or 43 mm
Adjustable tilt angle variable to 450
Adjustable parallel fence 8-190 mm
Drill depth max. 170/470 mm
Drill bit length max. 320/650 mm
Weight 3.3/4.2 kg
• pivots up to 45 degrees, with
centrepoint indicators for perfect
alignment
• smooth action due to precision guide
rods and slide bearings
• stable operation due to robust
baseplate and 3-position side handle
• precise guidance of drill/auger
bits with the centering plate
• dual, lockable depth gauges
• dual parallel fences for precise and
fast set-up.
• can be used with any drill with a
43/57mm collar
GDP 320 A
Includes: two depth gauges, two parallel gauges,
centering plate for drill bits diameter 8-28 mm,
adapter ring diameter 57/43 mm
GDP 320 A
in a carton
621 603
GDP 650 A
in a carton
621 605
Precise drill stands which pivot
up to 45 degrees
(also can be used with
core cutters, not included)
15
