Specifications

Make an impact with PROTOOL drills
Includes: Keyless chuck "AutoLock", side-handle,
drill bit depth gauge, in a Systainer.
Specifications
Power 760W
Speed 1st/2nd gear 0-1100/3050 rpm
Impacts/minute 1st/2nd gear 0-22000/61000
Max drill ¼ in steel/al/wood 20/13/45 mm
Torque 1st/2nd gear 44/15 Nm
Chuck clamping range 1.5-13 mm
Chuck thread 1/2”-20 UNF
Collar ¼ 43 mm
Weight
2.6 kg
PDP 20-2 EAQ-Plus
Fast bit changes with
"AutoLock" spindle lock
PDP 20-2 EAQ-Plus
623 113
in a Systainer
• multi-functional: hammer drilling,
drilling and fastening
• 2-speed gearbox with variable
speed to suit a range of materials
• one-handed bit changes - keyless
chuck and automatic spindle lock
• built to last: with all-metal gearing,
alloy gearbox
• forward/reverse rotation for driving
and removing fasteners
• ergonomic rear handle and 360°
rotatable side handle
• well protected during transport in a
durable, handy Systainer
Includes: Keyed chuck, side-handle, depth gauge,
chuck key.
Specifications
Power 760W
Speed 1st/2nd gear 0-1100/3050 rpm
Impacts/minute1st/2nd gear 0-22000/61000
Max drill ¼ in steel/al/wood 20/13/45 mm
Torque 1st/2nd gear 44/15 Nm
Chuck clamping range 1.5-13 mm
Chuck thread 1/2”-20 UNF
Collar ¼ 43 mm
Weight 2.6 kg
PDP 20-2 EQ
Rugged, reliable performer with
2-speed gearbox
PDP 20-2 EQ
623 102
in a carton
• 2 speed gearbox with variable
speed to suit a range of materials
• built to last: with all-metal gearing,
alloy gearbox
• forward/reverse rotation for driving
and removing fasteners
• heavy-duty drive spindle and
spindle bearings
• carbide-metal jawed keyed chuck
• Plug it detachable lead system
Drilling Performance Comparison
PROTOOL PDP 20-2 EQ
Competitor brand A
Competitor brand B
Competitor brand C
Faster, Deeper, more Powerful
This drilling test, done in concrete (35
MPa), demonstrates the outstanding
performance of the PROTOOL PDP
20 impact drill range. This test was
conducted using maximum rpms in the
2nd gear setting, with a carbide tipped
10mm diameter drill bits, at 150N force.
Powerful, Fast, Reliable
The value of a good hammer drill
lies in its speed, power and durability.
Protool's rugged line of electric hammer
drills delivers exceptional value. They're
built for speed - at up to 61,000 bpm,
there's none faster - and they've got
an integrated spindle lock for fast,
one-handed bit changes. They're built
for construction work, with all metal
gearing, precision engineered spindle
and die-cast alloy housing and deliver
the power professional tradespeople
expect from a quality tool. And we back
them with a 3-year extended warranty.
Get the job done faster - get Protool.
14
