Specifications

7
Power, endurance, and ergonomics
with dual speed gears
Compact single speed drill for
general wood and metal drilling
DRP 10 EQ DRP 13-2 EQ
• high speed for quick, effecient
drilling
• variable speed for different
materials
• easy centering of holes due to
speed preset switch
• compact and ergonomic design
• plug it detachable lead system
• robust 2-speed gearbox in
durable aluminium-alloy housing
• variable speed for different
materials
• forward/reverse rotation for
driving and removing fasteners
• plug it detachable lead system
Specifications
Rated input 650 W
No-load speed 0-4000 rpm
Max drill ¼ in steel/al/wood 10/12/25 mm
Chuck capacity 1-10 mm
Spindle thread 1/2”-20 UNF
Weight 1.7 kg
Includes: Keyless chuck
DRP 10 EQ
631 183
in a carton
Specifications
Rated input 760 W
No-load speed 0-1000/3050 rpm
Maximum torque 44/15 Nm
Max drill ¼ in steel/al/wood 13/20/45 mm
Chuck capacity 1.5-13 mm
Spindle thread 1/2”-20 UNF
Weight 2.5 kg
Includes: Keyed chuck, telescopic side handle, chuck
key, drill bit depth gauge.
DRP 13-2 EQ
631 233
in a carton
Includes: Keyed chuck with locking device, telescopic
side handle, chuck key, drill bit depth gauge.
Specifications
Power 1100W
Speed 0-650 rpm
Max drill ¼ in steel/al/wood 20/28/65 mm
Maximum torque 98 Nm
Chuck capacity 3-16 mm
Spindle thread 5/8”-16 UN-2A
Weight 3.2 kg
DRP 20 ET
Ultra-high output torque drill
DRP 20 ET FF 633 365
in a carton
• super-high torque and robust design
make it ideal for engineers and
builders
• extended lifetime from robust alloy
housing, heavy duty drive spindle
and spindle bearings
• optimal performance for the
selected bit and material ensured
with electronic speed control
• forward/reverse rotation for easy
tightening and removal of fasteners
• keyed chuck with safety locking
device
Protool's standard range of electric drill/drivers
13
