Specifications

The DRP 20 FF QuaDrill series: the
innovative super-high torque drilling
system.
Protool's DRP 20 FF drills are perfectly suited
to demanding construction and engineering
work, delivering up to 98 Nm of torque for
drilling large diameter holes and driving large
fasteners. These rugged tools are built to last,
with full-wave electronics to prevent overload
and an alloy gear housing. The electronics
also protect you from kick-back injury and the
telescopic side handle prevents twist injuries
during high-torque operation.
The FastFix System sets them apart
Like the DRP 16 FF QuaDrill, it's the FastFix
chuck and accessory system that makes these
tools truly unique. In a tight spot? Just pop
on the angle attachment for easy access
anywhere - whether you're drilling or driving
large fasteners. Want a lighter, more compact
screwdriver? Simply remove the chuck to reveal
a ¼” hex recess bit holder. A ½” square drive
socket attachment is also available for driving
coach screws or running nuts.
Available in single- and two-speed gearbox
models, the DRP 20 FF QuaDrill is the only
super-torque drill/ driver system you'll need.
Specifications
Power 1100W
No-load speed 1st/2nd gear 0-1000/1800 rpm
Max drill ¼ in steel/aluminium/wood 20/28/50 mm
Maximum torque 62/35 Nm
Chuck capacity 3-16 mm
Weight 3.7 kg
QuaDrill
DRP 20-2 E FF
Includes: FastFix keyed chuck with locking device,
telescopic side handle, chuck key, drill bit depth
gauge.
DRP 20-2 E FF 632 860
in a carton
Dual-speed, high-torque drill
• 2 speed gearbox, exceptional
torque and FastFix system - ideal for
engineers and building trades
• converts to compact screwdriver -
easily remove chuck to reveal 1/4"
hex bit holder
• angle adapter snaps on for angle
drilling/ fastening in tight spots
(sold separately)
• accommodates 1/2" square drive
for sockets (sold separately)
• robust alloy housing, heavy duty
drive spindle and spindle bearings
• forward/reverse rotation
Specifications
Power 1100W
No-load speed 0-650 rpm
Max drill ¼ in steel/aluminium/wood 20/28/65 mm
Maximum torque 98 Nm
Chuck capacity 3-16 mm
Weight 3.7 kg
QuaDrill
DRP 20 ET FF
Includes: FastFix keyed chuck with locking device,
telescopic side handle, chuck key, drill bit depth
gauge.
DRP 20 ET FF 632 858
in a carton
• super-high torque and FastFix
system solve difficult on-site
problems for builders, sparkies and
plumbers
• converts to compact screwdriver
- easily remove chuck to fasten
drirectly using integrated 1/4" hex
bit holder
• angle adapter snaps on for angle
drilling/ fastening (sold separately)
• accommodates 1/2" square drive
for sockets (sold separately)
• robust alloy housing, heavy duty
drive spindle and spindle bearings
• forward/reverse rotation
Super-high torque drill
11
