TROUBLE SHOOTING GUIDE TROUBLE SHOOTING GUIDE
AIR LEAKS
AIR LEAKING FROM THE AIRPORT
 •ChecktheO-ringontheAirsystem.Ifneeded
change the O-ring and try again. The O-ring
normally used is #15 but some manufacturers
might use a different size. Consult the manual
of the air system you are using.
 •Checkthatthehoseconnectoristight.
Remove the hose from the connector by
pushing the gray plastic towards the connector
and pull out hose. Insert a
3
⁄16” Allen key into
the connector and tighten. If needed, remove
and apply thread sealant to the thread and
  re-tighten.Ifunsureconsultexpertadvice.
 •Checkthattheendofthehoseiscutstraight
and is not worn out. If needed cut a small piece
off the hose with a razor blade and re-insert
hose into the fitting. Make sure hose goes all
the way to the end.
 •Consultpage19forpindepressoradjustment.
AIR LEAKING FROM THE HYPER3™ REGULATOR
 •Firstlocatethepositionoftheleak.
 •For dis-assembly instructions consult the
technical section under Hyper3™ regulator.
 •Iftheleakiscomingfromthebottomofthe
regulator you will need to dis-assemble the
regulator and change the #010 O-ring and the
seat on the brass seat retainer mounted inside
the Hyper3™ regulator.
and the #014 O-ring located on the plunger.
Clean the gun bore, lube well and re-assemble.
 •Ifabovedoesn’thelp,makesurethattheboltis
screwed together snugly.
PROBLEMS WITH ELECTRONICS
SLG™ WON’T TURN ON
 •Makesurebatteryisnewandwellcharged.
 •Checkthatbatteryisconnectedtothe9Vclip
inside the SLG™ and that the other end of the
9V harness is connected to the board.
 •Makesurethereisnodirtordebrisblocking
the button from being pressed.
SLG™ WILL TURN ON / OFF BY ITSELF OR THE
EYES WILL TURN ON / OFF BY THEMSELVES
•Bothoftheseproblemsarecausedbecause
the button(s) are pressed all the time.
 •Removeboardfromtheframebyremoving
the grip panel on the left hand side,
disconnecting the cables and pulling the board
out. Carefully remove the two buttons and
clean them well.
 •Re-assembleandtest.Ifproblemspersist,
contact authorized service center for board
replacement.
EYES WILL NOT WORK, LED KEEPS
BLINKING GREEN
 •Firstchangethebattery.Theeyesarenormally
the first thing to stop working when a battery
is dying.
 •Nexttrytocleantheeyes.Youcaneitheruse
canned air and blow out the eye holes through
the feed neck hole or remove the eye plates
with a
1
⁄16” Allen key, pull out the eyes from the
mounting holes carefully and clean them with
q-tips. To test if the eyes work make sure there
is nothing inside the breech and that the bolt is
in the back position. Turn on the SLG™, the
light should be red after the boot up sequence.
If it is, the eyes are working.
 •Checkthattheeyewireisconnectedtothe
board so that metal clips are facing down.
 •IfnothingabovehelpscontactastoreorDYE
Precision for eye replacement.
SOLENOID WILL NOT ACTIVATE /
TRIGGER NOT WORKING
 •Checkthatthetriggeradjustmentisnotset
so that the microswitch cannot activate.
You should hear a small click when pulling
the trigger.
 •IftheSLG™resoncewhenturnedonbut
not after that your trigger is set so that the
micro switch is always activated. Re-adjust
the trigger.
 •IfthetriggeriscorrectlyadjustedbuttheSLG™
still won’t fire check that the microswitch
cable is well inserted into the board and to the
correct connector (the microswitch connector
is white and plugs into the white female
connector on the board).
 •If the leak is from the top of the regulator
change the #012 O-ring on the outside of
the cap.
 •Otherwise consult a trained Tech to repair
the Hyper3™.
AIR LEAKING FROM THE ASA
 •Changethe#011O-ringonthetopcapof
the Hyper3™ and apply a small amount of lube
to the O-ring.
AIR LEAKING BETWEEN BODY AND FRAME
 •Oneofthegaspassagescouldbeleaking.
Gas up the SLG™ without the frame attached
  andtrytolocatetheexactpointofleakage.
If leak is coming from one of the blocked holes
remove the screw, apply some thread sealant
and re-attach screw to the body.
AIR LEAKING FROM BACK OF THE SLG™
 •Checkthattheboltkitistightenedalltheway
into the SLG™. If the bolt kit is loose, it will
start to leak.
 •Ifabovedoesnotsolvetheleak,removethe
bolt kit and change the #020 O-ring on the
back part of the bolt.
 •Replacethe#O12O-ringontheplunger.
 •Ifleakpersists,replacethetwo#005O-rings
on the bleed button.
AIR LEAKING FROM FRONT OF THE SLG™
 •RemovetheBoltkitfromthemarkerand
change the front #016 O-ring on the bolt
