User Manual

5
Button Function
MENU Button • Browse interface
• Setting parameter
SET Button • Load ON/OFF
• Clear error
• Enter into Set Mode
• Save data
LCD Display
Status Display
Item Icon Status
Day
Night
PV Array No Charging
Charging
PV Voltage, Current, Power
Battery capacity, in charging
Battery Battery voltage, current, temperature
Battery type
Load ON
Load Load OFF
Load voltage, current, load mode
OPERATION
Button Function
