REPLACEMENT PARTS LIST

For replacement parts, call our customer

service department at 1-866-389-8827,

8 a.m. - 8 p.m., EST, Monday - Friday.

PART DESCRIPTION PART#

1 Metal Handle A662B00

2 Handle Cap A66D558

3 Screw (3/16" -24 * 3-9/16" L) A608550

4 Escutcheon Assembly A667915

5 Screw (3/16" -24 * 2-3/16" L) A608519

6 Plaster Guard A127223

7 Retainer Nut A103322

8 Sleeve A103310-Z

9 Ceramic Disc Cartridge A507190

10 Cartridge Assembly A507040

11 Plug A028452

12 Shower Arm Flange A019001-S

13 Shower Arm A020002-S

14 Shower Head S1213300

15 Spout w/ Diverter A152125
