User Manual Steamer PBDS4510X
Progress CONTENTS Safety information Safety instructions Product description Control panel Before first use Daily use Clock functions 2 3 6 6 8 9 10 Automatic programmes Using the accessories Additional functions Hints and tips Care and cleaning Troubleshooting Technical information 11 12 13 14 18 21 22 Subject to change without notice. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions.
Progress 3 General Safety • • • • • • • • • Only a qualified person must install this appliance and replace the cable. WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. Always use oven gloves to remove or put in accessories or ovenware. Before maintenance cut the power supply.
Progress • Always use a correctly installed shockproof socket. • Do not use multi-plug adapters and extension cables. • Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre. • Do not let mains cables touch or come near the appliance door, especially when the door is hot.
Progress 5 damage to the appliance, the housing unit or the floor. Do not close the furniture panel until the appliance has cooled down completely after use. Steam Cooking WARNING! Risk of burns and damage to the appliance. • Released Steam can cause burns: – Do not open the appliance door during the steam cooking operation. – Open the appliance door with care after the steam cooking operation. Care and cleaning WARNING! Risk of injury, fire, or damage to the appliance.
Progress PRODUCT DESCRIPTION General overview 1 2 4 4 7 1 2 3 4 5 6 7 3 3 2 1 5 Control panel Electronic programmer Water drawer Lamp Steam generator with cover Shelf support, removable Shelf positions 6 Accessories Sponge Wire shelf For absorbing the remaining water from the steam generator. For cookware, cake tins, roasts.
Progress 7 Use the sensor fields to operate the appliance. Sensor Field Function Description - DISPLAY Shows the current settings of the appliance. ON / OFF To activate and deactivate the appliance. OPTIONS To set an oven function, a cleaning function or an automatic programme (only when the appliance is activated). MY FAVOURITE PROGRAMME To store your favourite programme. Use it to have access to your favourite programme directly or when the appliance is deactivated.
Progress Other indicators of the display: Symbol / / Name Description Automatic programme You can choose an automatic programme. My favourite programme The favourite programme operates. kg / g An automatic programme with a weight input operates. h / min A clock function operates. Temperature The current temperature is indicated. Temperature You can change the temperature. Light You deactivated the light. Minute minder The minute minder function operates.
Progress 9 DAILY USE WARNING! Refer to Safety chapters. Operating the appliance generator with the sponge. If necessary, clean the steam generator with some vinegar. Let the appliance dry fully with the door open. To operate the appliance you can use: Changing the temperature • the manual mode • automatic programmes Touch or to change the temperature in steps of 5 °C. When the appliance is at the set temperature, an acoustic signal sounds three times and the Heat up indicator goes out.
Progress – Use the residual heat to warm up other foods. • Cooking with fan - when possible, use the cooking functions with fan to save energy. • Residual heat – In some oven functions if a programme with time selection (Duration, End, Time Delay) is activated and the cooking time is longer than 30 minutes, the heating elements deactivate automatically 10% earlier. The fan and lamp continue to operate.
Progress 11 Setting the END 1. Activate the appliance and set an oven function and temperature. 2. Touch again and again until the display shows . flashes in the display. or to set the END and 3. Use or to confirm. First you set the minutes and then the hours. When the set time ends, an acoustic signal sounds for two minutes. symbol and the time setting flash in the display. The appliance deactivates. 4. Touch a sensor field or open the oven door to stop the acoustic signal. 5. Deactivate the appliance.
Progress Programme number Programme name 5 SMALL PIKE DUMPLINGS 6 FLAN CARAMEL 7 COCONUT PUDDING 8 CHOCOLATE CREAM 9 ESPRESSO FLAN 10 STUFFED LETTUCE 11 CAULIFLOWER FLAN 12 ASPARGUS FLAN 13 SPINACH TERRINE 14 VEGETABLES, MEDITERRANEAN 15 VEGETABLES, TRADITIONAL 16 PEELING TOMATOES 17 POTATOES IN THEIR JACKET 18 BOILED POTATOES 19 RICE 20 GNOCCHI Automatic programmes 1. Activate the appliance. . 2. Touch The display shows and the number of the automatic programme. 3.
Progress 13 • All accessories have small indentations at the top of the right and left side to increase safety. The indentations are also anti-tip devices. • The high rim around the shelf is a device which prevents cookware from slipping. ADDITIONAL FUNCTIONS Using My Favourite Programme function To deactivate the Child Lock function repeat step 2. Use this function to save your favourite temperature and time settings for an oven function or programme. Using the Function Lock 1.
Progress Description Value to set 1 RESIDUAL HEAT INDICATOR ON / OFF 2 KEY TONE1) CLICK / BEEP / OFF 3 FAULTY TONE ON / OFF 4 SERVICE MENU - 5 RESTORE SETTINGS ON / OFF 1) It is not possible to deactivate the tone of the ON / OFF sensor field. 1. When the appliance is deactivated, touch and hold for three seconds. The display shows SET1 and "1" flashes. or to set the setting. 2. Touch 3. Touch . 4. Touch or to change the value of the setting. 5. Touch .
Progress 15 • When you cook longer than 30 minutes or when you cook large quantities of food, add water if it is necessary. • Put the food into the correct cooking containers and put the containers on the shelves. Make sure that there is some distance between the shelves to let the steam circulate around each container. • After each use, remove the water from the water drawer, connecting hoses and steam generator. Refer to the chapter "Care and cleaning". • The tables give data for typical dishes.
Progress Food Temperature (°C) Time (min) Shelf position Water in the water drawer (ml) Cauliflower, florets 96 25 - 30 1 500 Broccoli, whole 96 30- 40 1 550 Broccoli, florets 96 20 - 25 1 400 Mushroom slices 96 15 - 20 1 400 Peas 96 20 - 25 1 450 Fennel 96 35 - 45 1 600 Carrots 96 35 - 45 1 600 Kohlrabi, strips 96 30 - 40 1 550 Peppers, strips 96 15 - 20 1 400 Leeks, rings 96 25 - 35 1 500 Green beans 96 35 - 45 1 550 Lamb's lettuce, florets
Progress 17 Side dishes / accompaniments Food Temperature (°C) Time (min) Shelf position Water in the water drawer (ml) Yeast dumplings 96 30 - 40 1 600 Potato dumplings 96 35 - 45 1 600 Unpeeled potatoes, medium 96 45 - 55 1 750 Rice (water / rice ratio 1.
Progress Meat Food Temperature (°C) Time (min) Shelf position Water in the water drawer (ml) Cooked ham 1000 g 96 55 - 65 1 800 + 150 Chicken breast, poached 90 25 - 35 1 500 Chicken, poached, 1000 - 1200 g 96 60 - 70 1 800 + 150 Veal / pork loin without leg, 800 - 1000 g 90 80 - 90 1 800 + 300 Kasseler (smoked loin of pork), poached 90 70 - 90 1 800 + 300 Tafelspitz (prime boiled beef) 96 110 - 120 1 800 + 700 Chipolatas 80 15 - 20 1 400 Food Temperature (°C) T
Progress 19 • If you have nonstick accessories, do not clean them using aggressive agents, sharp-edged objects or a dishwasher. It can cause damage to the nonstick coating. Removing the shelf supports Before maintenance, make sure that the appliance is cool. There is a risk of burns. To clean the appliance, remove the shelf supports. 1. Pull carefully the supports up and out of the front catch. 1 3 2 2. Pull the front end of the shelf support away from the side wall. 3.
Progress A A 3. Close the door until it is at an angle of approximately 45°. 9. Clean the glass panel with water and soap. Dry the glass panel carefully. When the cleaning is completed, install the glass panels and the door. Do the above steps in the opposite sequence. Install the smaller panel first, then the larger. Replacing the lamp Put a cloth on the bottom of the interior of the appliance. It prevents damage to the lamp glass cover and the cavity. 45° 4.
Progress 21 The side lamp 1. Remove the left shelf support to get access to the lamp. 2. Use a Torx 20 screwdriver to remove the cover. 3. Remove and clean the metal frame and the seal. 4. Replace the lamp with a suitable 300 °C heat-resistant lamp. 5. Install the metal frame and the seal. Tighten the screws. 6. Install the left shelf support. TROUBLESHOOTING WARNING! Refer to Safety chapters. What to do if... Problem Possible cause Remedy The appliance does not heat up.
Progress Problem Possible cause Remedy The display shows an error code that is not in this table. There is an electrical fault. Deactivate the oven with the house fuse or the safety switch in the fuse box and activate it again. If the display shows the error code again, contact the Customer Care Department. Service data the front frame of the appliance cavity. Do not remove the rating plate from the appliance cavity.
