Installation Guide

Incandescent 4” Open Recessed
IC & Non-IC
Type
 -09 -28
 P8041
Finish
Brushed Dimensions (Inches)
Catalog No. Nickel White A B
P8041 -09 -28 5 4
Rev. Rev. 01/15
Lamp Wattage
Housing IC Non-IC
P830-TG N/A 50w PAR20,R20
P832-TG N/A 50w PAR20,R20
P831-AT N/A 50w PAR20,R20
P831-FB 50w PAR20,R20 50w PAR20,R20
Specifications:
Flange
• Flange is brushed in same finish
• Integral to trim
• No light leaks around trim flange
• Covers irregular ceiling openings
Trim
• All aluminum construction
• Socket mounts to trim for optimum
performance and consistent lamp
position
• Trim is shipped with retention for solid
mounting in housing
• Splay design optimally accommodates
long neck Par20 lamps
Labels
• UL-CUL damp location listed
• Rated IC and Non-IC
Photometrics
• Refer to PAR20/r20 Lamp Application
Data
B
A
Progress Lighting
701 Millennium Blvd.
Greenville, South Carolina
29607
www.progresslighting.com
