2 Specifications
Item
Description
Cooling Method Natural air circulation
Weight 170g[0.4lb] or less
External Dimensions W110mm[4.33in]xH40mm[1.57in]xD27mm[1.06in]
Item
Description
Rated Voltage DC5V(supplied from the Display)
Power Consumption 1.25W or less
Voltage Endurance AC1000V 20mA 1min(When attached to the Display)
Insulation Resistance DC500V 10MΩ or higher(When attached to the Display)
.2.1 Electrical
.2.2 Environmental
.2.3 Structural
Item Description
Ambient Operating Temperature
0
o
C to +50
o
C
Storage Temperature
-20
o
C to +60
o
C
Ambient Humidity
10%RH to 90%RH
(No condensing,wet bulb temperature:39
o
C or less)
Storage Humidity
10%RH to 90%RH
(No condensing,wet bulb temperature:39
o
C or less)
Dust 0.1mg/m
3
and below(non-conductive levels)
Pollution Degree Pollution Degree 2
Atmosphere Free of corrosive gases
Air Pressure Vibration Resistance
(available altitude)
800hpa to 1114hpa(2000m above sea level or lower)
Vibration Resistance
IEC61131-2compliant
5Hz to 9Hz single-amplitude 3.5mm
9Hz to 150Hz constant-accelerated velocity 9.8m/s
2
X,Y,Z directions for 10cycles(100minutes)
Concussion Resistance IEC61131-2 compliant(147m/s
2
,XYZ directions 3times each)
Noise Immunity
Noise Voltage:1000Vp-p
Pulse Duration:1µs
Rise Time:1ns
(via noise simulator)
Electrostatic Discharge Immunity 6kV(complies with EN 61000-4-2 level3)
