User Manual
Wireless LAN Access Point(RFMD) User Manual
25
7. Specifications:
Standard compatibility
IEEE802.11b, FCC, RTSI, Wi-Fi compatible
All major networking standards, including IP, IPX
Wireless Network Interface: IEEE 802.11b (CSMA/CA)
Wired Network Interface: RJ45(10Base-T)
Encryption: 64-bit WEP and 128-bit WEP
Environmental
Operating Temperature is from 32л to 131л (0к to 55к)
Humidity (non-condensing): 10 to 90%
Power specification
Power Consumption: 5V5%@700mA
Power Requirements: 110-120V/220-240V
Radio Specifications
RF Output Power: 15 dBm
Modulation Technique: Direct Sequence Spread SpectrumΘ
CCK@5Mbps/11MpbsΘDQPSK@2MpbsΘDBPSK@1Mpbs
Typical Range: *50m indoors, 100m outdoors when 11Mbps
(May vary depending on operation environment)
Frequency range: 2.4-2.4835 GHz
Number of channels :14 channels
Antenna: Embedded Antenna Modulation with diversity support
Physical Dimensions
Length 130mm*Height 190mm*Width 66mm
Weight: 330g
Other Function
Led Indicators: Status, network activity and RF Activity
