User's Manual

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

 Top Shelf

 Boom Shelf

 4x Pneumac Wheels

 4x Rods

 2x Cross Bars

 2x Handles

Victor V1.1 Video Producon Cart (VCTR-V1)

Assembly Manual

Available Sizes: 32”, 36”

PAGE 1
Victor V1.1 Video Production Cart (VCTR-V1) Assembly Manual Available Sizes: 32”, 36” What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.       Top Shelf Bottom Shelf 4x Pneumatic Wheels 4x Rods 2x Cross Bars 2x Handles All rights reserved.
PAGE 2
Victor Cart Setup  Open all the 4 locks of Trolley to take out all the parts, as shown in image.  Unlock 4 Pneumatic Wheels and slide onto Trolley’s Bottom Shelf, as shown in image.  After sliding the wheels, lock them with the knob on top. NOTE: To keep the dolly in static position, lock the wheels by pushing down the lever.  Now insert all the 4 Rods into 4 corners of Bottom Shelf. Tighten the knobs properly to secure them.
PAGE 3
 Insert the crossbar and secure with provided knob.  Insert the handle onto the rods, Set the desired height position as shown in image. YOUR PROAIM VICTOR V1.1 VIDEO PRODUCTION CAMERA CART ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts.
