User`s manual

22 3
PART LIST—Model No. PFEVEL39830 R0803A
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.
1 1 Frame
2 1 Upright
3 1 Left Side Shield
4 1 Right Side Shield
5 2 Handlebar Arm
6 1 Left Handlebar
7 1 Idler Assembly
8 1 Right Handlebar
9 1 Rear Stabiliser
10 1 Front Stabiliser
11 1 Left Pedal Arm
12 1 Right Pedal Arm
13 1 Left Pedal
14 1 Right Pedal
15 2 Pedal Disc
16 2 Disc Crossbar
17 1 Flywheel
18 1 Side Shield Bracket
19 1 Drive Belt
20 2 Rear Endcap
21 2 Front Endcap
22 2 Wheel
23 1 Console
24 2 Handgrip
25 2 M5 x 14mm Screw
26 1 M8 x 22mm Flat Head Bolt
27 2 M10 x 74mm Button Bolt
28 4 M6 Nylon Locknut
29 1 Resistance Motor
30 2 Large Snap Ring
31 2 Large Bearing
32 1 Pedal Axle
33 7 M10 Nylon Locknut
34 4 M10 x 75mm Carriage Bolt
35 2 M8.5 Washer
36 6 M4 x 19mm Flange Screw
37 4 Pedal Arm Bushing
38 7 M8 Nylon Locknut
39 1 Large Flywheel Washer
40 2 Pedal Arm Bolt Set
41 2 M6 x 72mm Bolt
42 2 M4 x 22mm Screw
44 1 Upper Wire
45 2 M5 x 16mm Bolt
46 2 Handlebar Cap
47 2 Handlebar Spacer
48 2 Frame Spacer
49 4 Small Handlebar Arm Bushing
50 4 M8 x 45mm Button Bolt
51 4 M6 x 25mm Screw
52 14 M4 x 16mm Screw
53 1 Reed Switch/Wire
54 1 Cable Clamp
55 2 M10 Washer
56 2 M8 x 19mm Shoulder Screw
57 1 M10 Flat Head Bolt
58 1 Magnet
59 2 M10 Split Washer
60 4 Large Handlebar Arm Bushing
61 2 5/16” x 25.4mm Hex Bolt
62 1 M10 x 60mm Screw
63 1 Bottle Holder
64 4 M4 x 25mm Screw
65 2 Handlebar Endcaps
66 2 M5 Nylon Locknut
67 4 M5 Washer
68 1 Small Flywheel Washer
69 2 M5 x 16mm Screw
70 1 Lower Wire
71 2 M6 x 18mm Bolt
72 4 M6 x 28mm Screw
# 1 TCD Cable
# 2 Hex Key
# 1 Grease
# 1 User’s Manual
Key No. Qty. Description Key No. Qty. Description
1. Read all instructions in this manual before
using the elliptical trainer. Use the elliptical
trainer only as described in this manual.
2. It is the responsibility of the owner to ensure
that all users of the elliptical trainer are ade-
quately informed of all precautions.
3. The elliptical trainer is intended for in-home
use only. Do not use the elliptical trainer in a
commercial, rental, or institutional setting.
4. Place the elliptical trainer on a level surface,
with a mat beneath it to protect the floor or
carpet. Keep the elliptical trainer indoors,
away from moisture and dust.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under the age of 12 and pets
away from the elliptical trainer at all times.
7. The elliptical trainer should not be used by
persons weighing more than 115 kg (250
lbs.).
8. Always wear appropriate clothes when
using the elliptical trainer. Always wear ath-
letic shoes for foot protection.
9. Always hold the pulse sensor or the handle-
bars when mounting, dismounting, or using
the elliptical trainer.
10. The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determin-
ing heart rate trends in general.
11. Each time you stop exercising on the ellipti-
cal trainer, allow the pedals to come to a
complete stop before dismounting.
12. Always keep your back straight when using
the elliptical trainer. Do not arch your back.
13. If you feel pain or dizziness whilst exercis-
ing, stop immediately and cool down.
IMPORTANT PRECAUTIONS
WARNING:
To reduce the risk of serious injury, read the following important precau-
tions before using the elliptical trainer.
WARNING:
Before beginning this or any exercise program, consult your physician.
This is especially important for persons over the age of 35 or persons with pre-existing health
problems. Read all instructions before using. ICON assumes no responsibility for personal injury
or property damage sustained by or through the use of this product.
