Operating Instructions
Forward
To go forward: pull backward (squeeze) the throttle trigger on the transmitter.
Forward
Backward
To go backward (reverse): push forward on the transmitter throttle trigger.
Backward
Left Turn
To turn left rotate the steering wheel counter-clockwise (towards yourself). Use the throttle trigger to drive
the boat forward and left.
Left Turn
Right Turn
To turn right rotate the steering wheel clockwise (away from yourself). Use the throttle trigger to drive the
boat forward and right.
Right Turn
Self-Righting
If the boat capsizes in the water, push the throttle trigger forward and then quickly pull it backward. The boat will
automatically right itself.
12
Limited Warranty
What this Warranty Covers
Horizon Hobby, LLC (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be
free from defects in materials and workmanship at the date of purchase.
What is Not Covered
This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God,
accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or
maintenance, (iii) modifi cation of or to any part of the Product, (iv) attempted service by anyone other than a
Horizon Hobby authorized service center, (v) Product not purchased from an authorized Horizon dealer, or (vi)
Product not compliant with applicable technical regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES NO OTHER WARRANTY OR REPRESENTATION,
AND HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE
IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY
MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.
Purchaser’s Remedy
Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will, at its option, either
(i) service, or (ii) replace, any Product determined by Horizon to be defective. Horizon reserves the right to inspect
any and all Product(s) involved in a warranty claim. Service or replacement decisions are at the sole discretion of
Horizon. Proof of purchase is required for all warranty claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY.
Limitation of Liability
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS
OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM
IS BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF
LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event
shall the liability of Horizon exceed the individual price of the Product on which liability is asserted. As Horizon has
no control over use, setup, fi nal assembly, modifi cation or misuse, no liability shall be assumed nor accepted for
any resulting damage or injury. By the act of use, setup or assembly, the user accepts all resulting liability. If you
as the purchaser or user are not prepared to accept the liability associated with the use of the Product, purchaser
is advised to return the Product immediately in new and unused condition to the place of purchase.
Law
These terms are governed by Illinois law (without regard to confl ict of law principals). This warranty gives you
specifi c legal rights, and you may also have other rights which vary from state to state. Horizon reserves the right
to change or modify this warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services
Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup
or use of the Product has been started, you must contact your local distributor or Horizon directly. This will enable
Horizon to better answer your questions and service you in the event that you may need any assistance. For
questions or assistance, please visit our website at www.horizonhobby.com, submit a Product Support Inquiry, or
call the toll free telephone number referenced in the Warranty and Service Contact Information section to speak
with a Product Support representative.
Inspection or Services
If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in,
please use the Horizon Online Service Request submission process found on our website or call Horizon to obtain
a Return Merchandise Authorization (RMA) number. Pack the Product securely using a shipping carton. Please note
that original boxes may be included, but are not designed to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and insurance for lost or damaged parcels, as Horizon is not
responsible for merchandise until it arrives and is accepted at our facility. An Online Service Request is available at
http://www.horizonhobby.com/content/_service-center_render-service-center. If you do not have internet access,
please contact Horizon Product Support to obtain a RMA number along with instructions for submitting your
product for service. When calling Horizon, you will be asked to provide your complete name, street address, email
address and phone number where you can be reached during business hours. When sending product into Horizon,
please include your RMA number, a list of the included items, and a brief summary of the problem. A copy of your
original sales receipt must be included for warranty consideration. Be sure your name, address, and RMA number
are clearly written on the outside of the shipping carton.
NOTICE: Do not ship LiPo batteries to Horizon. If you have any issue with a LiPo battery, please
contact the appropriate Horizon Product Support offi ce.
Left and Right Trim Adjustments
Let the boat drive straight ahead (release the rudder wheel). If the boat turns to the left or right the steering trim
may need to be adjusted. Adjust the Left or Right Trim until the boat sails straight.
Right TrimLeft Trim
Right Rudder TrimLeft Rudder Trim
Forward and Backwards Trim Adjustments
Let the boat idle (release the throttle trigger). If the boat still moves forward or backward, press the Forward or
Backward trim button as needed until the boat stops moving.
Backwards TrimForward Trim
Backwards TrimForward Trim
Recommended Tools and Materials
• Needle nose pliers
• Paper towel
• Nut driver: 5.5mm
• Phillips screwdriver: #1
• Clear tape (DYNM0102)
• Dynamite
®
Marine Grease and Gun (DYNE4200)
Warranty Requirements
For Warranty consideration, you must include your original sales receipt verifying the proof-of-purchase date.
Provided warranty conditions have been met, your Product will be serviced or replaced free of charge. Service or
replacement decisions are at the sole discretion of Horizon.
Non-Warranty Service
Should your service not be covered by warranty, service will be completed and payment will be required without
notifi cation or estimate of the expense unless the expense exceeds 50% of the retail purchase cost. By submitting
the item for service you are agreeing to payment of the service without notifi cation. Service estimates are available
upon request. You must include this request with your item submitted for service. Non-warranty service estimates
will be billed a minimum of ½ hour of labor. In addition you will be billed for return freight. Horizon accepts money
orders and cashier’s checks, as well as Visa, MasterCard, American Express, and Discover cards. By submitting any
item to Horizon for service, you are agreeing to Horizon’s Terms and Conditions found on our website http://www.
horizonhobby.com/content/_service-center_render-service-center.
ATTENTION: Horizon service is limited to Product compliant in the country of use and ownership.
If received, a non-compliant Product will not be serviced. Further, the sender will be responsible
for arranging return shipment of the un-serviced Product, through a carrier of the sender’s choice
and at the sender’s expense. Horizon will hold non-compliant Product for a period of 60 days from
notifi cation, after which it will be discarded.
Country of
Purchase
Horizon Hobby Contact Information Address
United States of
America
Horizon Service Center
(Repairs and Repair Requests)
servicecenter.horizonhobby.com/
RequestForm/
4105 Fieldstone Rd
Champaign, Illinois, 61822 USA
Horizon Product Support
(Product Technical Assistance)
www.quickbase.com/db/
bghj7ey8c?a=
GenNewRecord
888-959-2306
Sales
[e-mail]
888-959-2306
China Service/Parts/Sales:
Horizon Hobby - China
[e-mail]
[phone]
Room 506, No. 97 Changshou
Rd. Shanghai, China 200060
FCC Information
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifi cations not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This product contains a radio transmitter with wireless technology which has been tested and found to be compliant
with the applicable regulations governing a radio transmitter in the 2.400GHz to 2.4835GHz frequency range.
