TABLE OF CONTENTS INTRODUCTION Introduction About This Guide.................................................................................. 1 PRG Lighting Product Documentation ................................................. 1 About This Guide Components V676 Console ....................................................................................... 2 Virtuoso Consoles ................................................................................ 3 Virtuoso VX Console ........................
COMPONENTS V676 Console Function Capacities: + Channels: 2,000 multiple parameter luminaires V676 Console The V676® Console is a lighting control desk capable of operating automated luminaires, conventional fixtures and media servers. The console supports up to 702 DMX universes when used with PRG Node Plus units. Each PRG Node Plus has an internal processor and provides six universes of DMX512 and one Art-Net output.
Virtuoso Consoles The PRG Virtuoso® family of consoles offer powerful control options for all types of lighting systems. The consoles can be programmed online or offline; using a combination of desk buttons, touch screens and software windows. Virtuoso VX Console features: + Control of 2,000 multiple parameter luminaires. + 2,000-10,000 cues per fixture (luminaire dependent). + 1,000 presets. + 1,000 effects.
Virtuoso DX2 Console Like the Virtuoso® VX model, the Virtuoso DX2 is a control desk capable of operating automated luminaires, conventional fixtures and media servers. The console utilizes Virtuoso protocol and/or DMX512 to control the fixtures. The basic difference is the smaller size front panel desk. Virtuoso DX2 Console features: + Control of 2,000 multiple parameter luminaires. + 2,000-10,000 cues per fixture (luminaire dependent). + 1,000 presets. + 1,000 effects. + 200 beam selects.
PRG Series 400 Distribution Rack + 3U of additional rack space for adding third-party signal processing devices The PRG Series 400® Data and Power Distribution Rack offers significant features, both standard and superior to other power distribution systems. + Modular Design + Weighs a maximum of 305 lbs. when fully loaded The Series 400 system consists of a Rolling Rack unit, up to six 3U Breaker Modules, and associated Breakout Boxes connected by Trunk Cables.
Rack Breakout Box The Rack unit is the main power and data distribution hub for the Series 400 system. The Rack houses up to six Breaker Modules of any type, which can include a Front of House Breaker Module. The Rack provides a built-in LED Meter Module that monitors system current and voltage, and additional space for installing optional expansion components such as a Virtuoso® Node. System-wide functions can be controlled at the Rack, including power up, power down and testing.
FOH Breakout Module features: + Ten standard DMX512 Inputs + Two 100BaseT Ethernet Inputs + Six Edison Style 120V Outlets + Six Neutrik® 208V Outlets + Digital Voltmeter with Selector Switch + Signal Routing Control and Display + Front Panel Flush Rocker Circuit Breakers + Safety Interlock with FOH Breaker Module Front of House Breaker Module The Front of House (FOH) Breaker Module provides two trunk outputs, with each circuit protected by an individual circuit breaker, for the purpose of routing power and
400 Amp Disconnect The PRG Series 400® 400 Amp Disconnect is a mandatory PRG safety device containing a three-phase, 400 Amp circuit breaker serving as a Main Breaker for high current AC power distribution systems. A Disconnect unit is required when 5-wire, 4/0 AWG feeder cables greater than 10 feet in length are connected from a house service greater than 400 Amps per phase to a portable power distribution system.
Ethernet Switches Series 400 10-Port Ethernet Switch The PRG Series 400® 10-Port Ethernet Switch provides a powerful and convenient interface between V676, Virtuoso or DMX512 control consoles and their control equipment. The 10Port Ethernet Switch offers two types of connections: isolated copper Ethernet ports and fiber optic ports.
Nodes Virtuoso Node Plus The Virtuoso® Node Plus provides a powerful and convenient interface between V676, Virtuoso or Art-Net compatible control consoles, pixel mapping from media servers, and subsequent control equipment which require either Art-Net or DMX512 control signals. The unit accepts high level commands in either V676, Virtuoso or Art-Net protocol and converts the data into six universes of DMX512. Virtuoso Node Plus features: + Accepts V676, Virtuoso and Art-Net control protocols.
Virtuoso Node Virtuoso® Node as an Art-Net Input Device The Virtuoso® Node provides a powerful and convenient interface between V676, Virtuoso or Art-Net compatible control consoles, pixel mapping from media servers, and subsequent control equipment which require DMX512 control signals. The unit accepts high level commands in either Virtuoso or Art-Net protocol and converts the data into six universes of DMX512. A Virtuoso Node running software v5.5 will also function as an Art-Net to DMX512 convertor.
Ethernet Cables Fiber Optic Cables The following is a list of standard Ethernet cables for use with PRG lighting systems. These cables meet the necessary quality specifications and are the only Ethernet cables that should be used with PRG systems. Fiber optic provides the ability to transmit more information, more quickly, over longer distances with high bandwidth, light-weight cabling. Fiber optic can reliably send data up 2 kilometers away without the need for repeaters.
DIAGRAMS V676 Console Systems S-400 TRUNK CABLE 10-PORT FIBER SWITCH UP TO 500 FT. FIBER TO OTHER FIBER SWITCHES (V676 DATA) FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A B A B NODE PLUS NODE PLUS Cat5e V676 CONSOLE NODE PLUS SERIES 400 RACK NODE PLUS NOTE: Cat5e V676 CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
S-400 TRUNK CABLE 7-PORT COPPER SWITCH UP TO 500 FT. TO OTHER SWITCHES 100 METER MAX. (V676 DATA) FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A B A B NODE PLUS NODE PLUS Cat5e V676 CONSOLE NODE PLUS NODE PLUS SERIES 400 RACK NODE PLUS NOTE: Cat5e V676 CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: 10-PORT FIBER SWITCH FIBER TO OTHER FIBER SWITCHES (V676 DATA) FIBER NODE PLUS CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE DMX V676 CONSOLE A B FOH A/B SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT.
10-PORT FIBER SWITCH FIBER TO OTHER FIBER SWITCHES (V676 DATA) FIBER NODE V676 CONSOLE NODE NODE FIBER V676 CONSOLE NODE NODE NOTE: CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FROM ANOTHER CONSOLE OR PRG 10-PORT SWITCH 10-PORT FIBER SWITCH TO NEXT RACK OF NODES FIBER NODE NODE NODE V676 CONSOLE NODE NOTES: NODE THIS SYSTEM SETUP CAN BE USED FOR INSERTING ANOTHER CONSOLE INTO A SYSTEM. CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
100 METER MAX 7-PORT COPPER SWITCH Cat5e V676 CONSOLE NODE NODE Cat5e NODE V676 CONSOLE NODE NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e V676 CONSOLE V676 CONSOLE Cat5e 7-PORT COPPER SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A A UP TO 500 FT. B TO OTHER SWITCHES 100 METER MAX.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e V676 CONSOLE 7-PORT COPPER SWITCH TO OTHER SWITCHES 100 METER MAX. FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT.
Virtuoso Console Systems S-400 TRUNK CABLE 10-PORT FIBER SWITCH UP TO 500 FT. FIBER TO OTHER FIBER SWITCHES (Virtuoso DATA) FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A B A B NODE PLUS NODE PLUS Cat5e VIRTUOSO CONSOLE NODE PLUS SERIES 400 RACK NODE PLUS NOTE: Cat5e VIRTUOSO CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
S-400 TRUNK CABLE 7-PORT COPPER SWITCH UP TO 500 FT. TO OTHER SWITCHES 100 METER MAX. (Virtuoso DATA) FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A B A B NODE PLUS NODE PLUS Cat5e VIRTUOSO CONSOLE NODE PLUS NODE PLUS SERIES 400 RACK NODE PLUS NOTE: Cat5e VIRTUOSO CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: 10-PORT FIBER SWITCH FIBER TO OTHER FIBER SWITCHES (Virtuoso DATA) FIBER VIRTUOSO CONSOLE NODE PLUS CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE DMX VIRTUOSO CONSOLE A B FOH A/B SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT.
10-PORT FIBER SWITCH FIBER TO OTHER FIBER SWITCHES (Virtuoso DATA) FIBER VIRTUOSO CONSOLE NODE NODE NODE FIBER NODE VIRTUOSO CONSOLE NODE NOTE: CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FROM ANOTHER CONSOLE OR PRG 10-PORT SWITCH 10-PORT FIBER SWITCH TO NEXT RACK OF NODES FIBER NODE NODE NODE VIRTUOSO CONSOLE NODE NOTES: NODE THIS VIRTUOSO SYSTEM SETUP CAN BE USED FOR INSERTING ANOTHER CONSOLE, SUCH AS A TECH CONSOLE, INTO A SYSTEM. CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
100 METER MAX. 7-PORT COPPER SWITCH Cat5e VIRTUOSO CONSOLE NODE NODE Cat5e NODE VIRTUOSO CONSOLE NODE NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
100 METER MAX 7-PORT COPPER SWITCH TO ADDITIONAL RACKS Cat5e VIRTUOSO CONSOLE NODE NODE NODE NODE Cat5e VIRTUOSO CONSOLE 24 POTENTIAL DMX UNIVERSES OUT NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
VIRTUOSO or V676 PROTOCOL 7-PORT COPPER SWITCH TO ADDITIONAL RACKS NODE NODE NOTES: THIS SYSTEM SETUP CAN BE USED TO INSERT DATA FROM ANOTHER RACK OR CONSOLE, AND FOR SENDING DATA TO ADDITIONAL RACKS. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
VIRTUOSO or V676 PROTOCOL 7-PORT COPPER SWITCH NODE NODE NOTES: THIS SYSTEM SETUP CAN BE USED TO INSERT DATA FROM ANOTHER RACK OR CONSOLE, AND FOR SENDING DATA TO ADDITIONAL RACKS. ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e VIRTUOSO CONSOLE VIRTUOSO CONSOLE Cat5e 7-PORT COPPER SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A A UP TO 500 FT. B TO OTHER SWITCHES 100 METER MAX.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e VIRTUOSO CONSOLE 7-PORT COPPER SWITCH TO OTHER SWITCHES 100 METER MAX. FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT.
NOTE: DMX ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e VIRTUOSO CONSOLE 7-PORT COPPER SWITCH FOH BREAKOUT MODULE S-400 TRUNK CABLE UP TO 500 FT. A FRONT OF HOUSE BREAKER MODULE TO OTHER SWITCHES 100 METER MAX.
NOTE: 1. Ethernet Links between NIF's need to be CAT5e CROSSOVER Cables. 2. Fiber Links can not exceed more then 5 pieces of any length cable between devices. 3. No more then 3 Nodes per NIF. 4. PRG 10-Port Fiber Switches can NOT be used in a NIF ring. VIRTUOSO CONSOLE "B" A B Virtuoso Fiber Optic Snake (Fiber & PowerCon) Fiber Optic Cable 5. All Ethernet Copper Connections made with PRG/Belden CAT5e Cable.
GrandMA Console Systems FIBER TO STAGE Cat5e M A FIBER TO ADDITIONAL NSP's 10-PORT FIBER SWITCH Cat5e TO ADDITIONAL NSP's M A GrandMA CONSOLE NSP Cat5e M A M A NSP GrandMA CONSOLE M A NSP 10-PORT FIBER SWITCH M A NSP FOR FOH DMX FRONT OF HOUSE NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
S-400 TRUNK CABLE 10-PORT FIBER SWITCH UP TO 500 FT. TO 2ND RACK USING FIBER (MaNet DATA) FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A B A B M A NSP M A Cat5e M A NSP GrandMA CONSOLE M A M A NSP NOTE: Cat5e GrandMA CONSOLE SERIES 400 RACK ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
M A DMX DMX GrandMA CONSOLE FRONT OF HOUSE BREAKER MODULE A B FOH A/B SWITCH A FOH BREAKOUT MODULE S-400 TRUNK CABLE UP TO 500 FT. B CONVENTIONAL LIGHTING CONSOLE 10-PORT FIBER SWITCH A B TO S400 RACK OR OTHER ARTNET DEVICE A B TO 2ND RACK USING FIBER (ArtNet DATA) NOTE: M A ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FIBER TO STAGE Cat5e M A 10-PORT FIBER SWITCH FIBER TO 2ND RACK OF NSP'S GrandMA CONSOLE M A Cat5e NSP M A M A NSP M A GrandMA CONSOLE NSP M A NSP 10-PORT FIBER SWITCH M A M A NSP NSP FOR FOH DMX M A NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FIBER TO STAGE 10-PORT FIBER SWITCH 10-PORT FIBER SWITCH Cat5e MAX 8 ArtNet UNIVERSES TO SERIES 400 RACK OR OTHER ArtNet DEVICES FIBER TO OTHER SWITCHES (ArtNet DATA) M A NOTES: GrandMA CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. Cat5e M A THIS SYSTEM CONFIGURATION CAN HAVE NO MORE THEN 8 Art-Net UNIVERSES.
S-400 TRUNK CABLE UP TO 500 FT. 10-PORT FIBER SWITCH FOH BREAKOUT MODULE FRONT OF HOUSE BREAKER MODULE TO 2ND RACK USING FIBER (MaNet DATA) M A A B A B Cat5e M A NSP GrandMA CONSOLE M A NSP M A M A Cat5e NSP GrandMA CONSOLE M A NSP NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
Hog Console Systems NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e HOG 3 CONSOLE HOG3 DMX PROCESSOR DMX FOH BREAKOUT MODULE A B FRONT OF HOUSE BREAKER MODULE FOH A/B SWITCH S-400 TRUNK CABLE UP TO 500 FT.
S-400 TRUNK CABLE UP TO 500 FT. 10-PORT FIBER SWITCH FOH BREAKOUT MODULE FRONT OF HOUSE BREAKER MODULE A Cat5e B A B HOG 3 CONSOLE FIBER TO OTHER RACKS OF DMX PROCESSORS HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR Cat5e HOG3 DMX PROCESSOR HOG 3 CONSOLE NOTE: SERIES 400 RACK ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
S-400 TRUNK CABLE UP TO 500 FT. 7-PORT COPPER SWITCH FOH BREAKOUT MODULE FRONT OF HOUSE BREAKER MODULE A Cat5e B A B HOG 3 CONSOLE TO OTHER RACKS OF DMX PROCESSORS HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR Cat5e HOG3 DMX PROCESSOR HOG 3 CONSOLE NOTE: SERIES 400 RACK ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FIBER TO STAGE 10-PORT FIBER SWITCH 10-PORT FIBER SWITCH FIBER TO 2ND RACK OF NODES Cat5e HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR HOG 3 CONSOLE Cat5e HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR HOG3 DMX PROCESSOR HOG 3 CONSOLE HOG3 DMX PROCESSOR NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE Cat5e HOG 3 CONSOLE HOG 3 CONSOLE Cat5e 10-PORT FIBER SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A A UP TO 500 FT.
NOTE: S-400 TRUNK CABLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE UP TO 500 FT.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE DMX HOG 2 CONSOLE A B FOH A/B SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT.
DMX DMX CONVENTIONAL LIGHTING CONSOLE NOTE: HOG 2 CONSOLE A B FOH A/B SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT. A B B ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE DMX HOG iPC CONSOLE A B FOH A/B SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE A UP TO 500 FT.
S-400 TRUNK CABLE UP TO 500 FT. 10-PORT FIBER SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A Cat5e B A B FIBER TO OTHER RACKS OF DMX PROCESSORS DMX PROCESSOR DMX PROCESSOR HOG iPC CONSOLE Cat5e DMX PROCESSOR HOG iPC CONSOLE DMX PROCESSOR NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
S-400 TRUNK CABLE UP TO 500 FT. 7-PORT COPPER SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A Cat5e B A B TO OTHER RACKS OF DMX PROCESSORS DMX PROCESSOR DMX PROCESSOR HOG iPC CONSOLE Cat5e DMX PROCESSOR HOG iPC CONSOLE DMX PROCESSOR NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FIBER TO STAGE 10-PORT FIBER SWITCH 10-PORT FIBER SWITCH Cat5e FIBER TO 2ND RACK OF NODES DMX PROCESSOR HOG iPC CONSOLE Cat5e DMX PROCESSOR DMX PROCESSOR DMX PROCESSOR HOG iPC CONSOLE DMX PROCESSOR NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
DMX DMX HOG iPC CONSOLE FRONT OF HOUSE BREAKER MODULE A B FOH A/B SWITCH A FOH BREAKOUT MODULE S-400 TRUNK CABLE B CONVENTIONAL LIGHTING CONSOLE 10-PORT FIBER SWITCH A B TO S400 RACK OR OTHER ARTNET DEVICE A UP TO 500 FT. B TO 2ND RACK USING FIBER (ArtNet DATA) NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
MagicQ 100 Console Systems FIBER TO STAGE 10-PORT FIBER SWITCH 10-PORT FIBER SWITCH FIBER TO 2ND RACK OF NODES NODE Cat5e NODE NODE MAGIC Q100 CONSOLE 18 POTENTIAL DMX UNIVERSES OUT NOTE: CONSOLE AND RACK JUMP MADE WITH FIBER OPTIC CABLE. Cat5e ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE DMX MAGIC Q100 CONSOLE A B FOH A/B SWITCH FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE S-400 TRUNK CABLE UP TO 500 FT.
S-400 TRUNK CABLE UP TO 500 FT. 7-PORT COPPER SWITCH FOH BREAKOUT MODULE FRONT OF HOUSE BREAKER MODULE A B TO OTHER NODES OR ARTNET DEVICE (ArtNet DATA) A B TO SERIES 400 RACK Cat5e NODE OR NODE PLUS MAGIC Q100 CONSOLE NODE OR NODE PLUS DMX OUT NOTE: Cat5e SERIES 400 RACK MAGIC Q100 CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FIBER TO STAGE 10-PORT FIBER SWITCH FIBER TO 2ND RACK 10-PORT FIBER SWITCH (ArtNet DATA) TO SERIES 400 RACK OR OTHER ARTNET DEVICES NODE OR NODE PLUS Cat5e DMX OUT FRONT OF HOUSE BREAKER MODULE MAGIC Q100 CONSOLE A B A B Cat5e MAGIC Q100 CONSOLE NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
DMX S-400 TRUNK CABLE UP TO 500 FT. DMX CONVENTIONAL LIGHTING CONSOLE FOH BREAKOUT MODULE 7-PORT COPPER SWITCH FRONT OF HOUSE BREAKER MODULE A B TO OTHER NODES OR ARTNET DEVICE A B (ArtNet DATA) TO SERIES 400 RACK Cat5e NODE OR NODE PLUS MAGIC Q100 CONSOLE NODE OR NODE PLUS DMX OUT NOTE: Cat5e SERIES 400 RACK MAGIC Q100 CONSOLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
Maxxyz Console Systems NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE DMX MAXXYZ CONSOLE A FRONT OF HOUSE BREAKER MODULE B FOH A/B SWITCH FOH BREAKOUT MODULE S-400 TRUNK CABLE A A UP TO 500 FT.
S-400 TRUNK CABLE 7-PORT COPPER SWITCH UP TO 500 FT. TO OTHER NODES OR ARTNET DEVICE OR SERIES 400 (ArtNet DATA) FRONT OF HOUSE BREAKER MODULE FOH BREAKOUT MODULE A B A B NODE OR NODE PLUS NODE Cat5e NODE MAXXYZ CONSOLE NODE NOTE: NODE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
FIBER TO STAGE Cat5e 10-PORT FIBER SWITCH FIBER TO 2ND RACK 10-PORT FIBER SWITCH (ArtNet DATA) NODE ADDITIONAL DMX OUTPUTS MAXXYZ CONSOLE NOTE: ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE: S-400 TRUNK CABLE ALL ETHERNET COPPER CONNECTIONS MADE WITH PRG/BELDEN CAT5E CABLE. TRUNK CABLE DMX CABLE Cat5e CABLE UP TO 500 FT.
