72 BEST BOY
®
WASH LUMINAIRE USER MANUAL
Best Boy Wash Luminaire
SOURCE: HTI 1500 lamp optics optimized for 60,000 lumens
OUTPUT: 60,000+ lumens
POWER DRAW: 10.5 Amps at 208V, 8.75 Amps at 240V. Auto-sensing voltage input range is 170V to
270V.
POWER FACTOR: 0.99
REFLECTOR: Precision glass reflector with cold mirror coating
ZOOM RANGE: 6:1 from a narrow beam of 10º to a wide flood of 60º
BEAM SIZE CONTROL: In addition to the zoom optics, a mechanical iris provides continuous beam size control
for both rapid changes and smooth, timed beam angle changes
DIMMING: Gray-scale glass dimmer for full-field dimming from 0% to 100% with accurate slow-
speed control and fast bumps
STROBE: Lightning fast strobe wheel
COLOR: CMY color system featuring three (3) crossfading color wheels of Cyan, Magenta, and
Yellow, plus one (1) fixed wheel with five (5) fixed filters
COLOR TEMP CONTROL: Adjustable color temperature wheel, range from 3,200K all the way up to 8,000K. Also
includes a minus green filter on the fixed color wheel
ROTATING GOBOS: One (1) indexable, rotating gobo wheel with four (4) gobos
OPERATING TEMP: 0° to 120°F (18° to 49°C)
CONTROL: Compatible with all PRG consoles and a wide variety of DMX512 and Art-Net consoles
ON-BOARD CONTROL: Built-in LCD touchscreen display allows for on-board fixture control and feedback. On-
board battery power allows for the fixture address and configurations to be set without
having to apply AC power to the luminaire
DMX CHANNELS: 26 channels
PAN & TILT: Three-phase stepper motors
RANGE: Pan - 540°, Tilt - 260°
POSITIONING: Can be mounted in any orientation
SPACING: Hangs on 29 inch (736 mm) centers
WEIGHT: 88 lbs (39.9 kg) without hooks
