SOFTWARE VERSION 1.0 WWW.PRG.
AutoPar®, Bad Boy®, Best Boy®, MBOX®, Nocturne®, PRG Series 400®, V476®, V676®, and Virtuoso® are trademarks of Production Resource Group, LLC, registered in the U.S. and other countries. All other brand names which may be mentioned in this manual are trademarks or registered trademarks of their respective companies. This manual is for informational use only and is subject to change without notice. Please check www.prg.com for the latest version.
FOREWORD Compliance Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation.
WARNING: INSTRUCTIONS FOR PROTECTION AGAINST INJURY TO PERSONS 1) Exterior surfaces of the luminaire will be hot during operation. Use appropriate safety equipment (gloves, eye protection, etc.) when handling and adjusting hot equipment and components. Service and maintenance should be performed only by qualified personnel as determined by the high pressure lighting fixture manufacturer. 2) Arc lamps generate intense heat. Disconnect power and allow lamp to cool for 5 minutes before relamping.
Notes de sécurité Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
Revision History This manual has been revised as follows: IV Version Release Date Notes BASIC April 14, 2014 Software version 1.0. Initial release.
TABLE OF CONTENTS Introduction About This Manual........................................................................................................................................................................ 1 Additional Documentation ............................................................................................................................................................ 1 Customer Service ............................................................................................
DMX512 Operation DMX Channel Mapping............................................................................................................................................................... Special Notes.............................................................................................................................................................................. Timing Channels ................................................................................................................
INTRODUCTION About This Manual This manual provides necessary information regarding product safety, installation, and operation for the following equipment: + Best Boy® Wash Luminaire Familiarizing yourself with this information will help you get the most out of your lighting system. WARNING: It is important to read ALL accompanying safety and installation instructions to avoid damage to the product and potential injury to yourself or others.
Customer Service For technical assistance, contact the PRG International Service Center or contact your nearest PRG office. Contact information for all PRG office locations can be found on our website at: www.prg.com PRG Dallas (International Service) 8617 Ambassador Row, Suite 120 Dallas, Texas 75247 USA Phone: 214.630.1963 Fax: 214.630.5867 Service Fax: 214.638.2125 Service Email: orders@prg.com For Best Boy support, please contact: Bestboysupport@prg.
1. DESCRIPTION This chapter contains an overview of luminaire features and components.
FEATURES Overview The Best Boy Wash Luminaire is a precision-engineered, automated fixture that generates over 60,000 lumens of light output. Features + SOURCE: HTI 1500 lamp optics optimized for 60,000 lumens + OUTPUT: 60,000+ lumens + POWER DRAW: 10.5 Amps at 208V, 8.75 Amps at 240V. Autosensing voltage input range is 170V to 270V. + POWER FACTOR: 0.
COMPONENTS Included Items The following illustration shows all items included with the luminaire: (2) Hanging Bracket Assemblies -- with Mega-Claw Truss Hook 21.9816.0863 AC Line Cord Power Cable 25.9812.0902.5 Safety Cable 22.9816.0033 2.3749A-75 Best Boy Wash Luminaire 20.9815.0001 2.3749H- Figure 1-1: Best Boy Wash Luminaire Included Items Replacement Items and Accessories The following items can be ordered from PRG. PRG P/N TEAM Ecode Accessory 21.9816.0863 - 22.9816.0033 2.3749A-75 23.
Major Components and Controls The following illustration shows the external luminaire components and controls. FRONT VIEW Hanging Bracket Assembly (2) Allows luminaire to be mounted on truss pipe. Upper Enclosure Houses power supply, ballast, Master Control Board (MCB), and provides Data In and Thru, and AC power connections. Also houses the Menu Touchscreen (see detail below). Yoke Assembly - Houses Yoke Driver Control Board, and Pan & Tilt motors.
A Locking Lever, located between the yoke and head, can be used to keep the head from rotating. Be sure to disengage the lock during operation.
Fixed Color Wheel Configuration The following drawing shows the standard Fixed Color Wheel configuration. Open Position #5 True UV Blue Position #1 Minus Green 41.9815.0310.01 41.9815.0310.09 Position #4 Real Green Position #2 Deep Red 41.9815.0310.05 41.9815.0310.02 Position #3 Orange 41.9815.0310.06 Figure 1-4: Fixed Color Wheel Standard Configuration Gobo Wheel Configuration The following drawing shows the standard Gobo Wheel configuration. Open Position #4 Radioactive Position #1 Slot 17.
2. INSTALLATION This chapter contains instructions for installing the luminaire. It includes instructions for connecting power and data, along with instructions for powering up the luminaire for the first time and addressing it within your system.
POWER AND DATA CABLING REQUIREMENTS Power The Best Boy Wash Luminaire requires standard AC power distribution from 200-240 VAC, 50/60 Hz, 12A maximum. The upper enclosure provides a Neutrik® PowerCon connector for power input. Use the provided AC Line Cord Cable Assembly (25.9812.0902.5) to connect power.
The XLR 5-pin connectors should be wired as follows: Pin/Wire Code to XLR Connectors DMX Thru Cable Pinout 1 Pin 2 Pin 3 Pin 4 Pin 5 Foil & Braided Shield 1st conductor of 1st twisted pair 2nd conductor of 1st twisted pair 1st conductor of 2nd twisted pair 2nd conductor of 2nd twisted pair Data (-) Data (+) Data (-) Data (+) 5 2 DMX In Cable Pinout Pin 1 4 5 1 4 3 Male Conn 2 3 Female Conn Note: Refer to the USITT Recommended Practice for DMX512 guide for additional information rega
DMX512 Male Termination Connector A male XLR DMX512 termination connector is required at the last luminaire (or "far end of the line") to prevent signal reflections. Signal reflections may cancel out the signal at certain line lengths, resulting in errors. The terminator is also necessary for software downloads and running tests on multiple luminaires. To construct your own connector, you will need the following components: + 5-pin, male XLR connector. + 120 ohm resistor.
INSTALLATION PROCEDURES Unpacking and Attaching Hanging Brackets The Best Boy Wash Luminaire can be hung horizontally or vertically from any structure designed to accommodate the load of this moving luminaire. Two provided Hanging Bracket Assemblies (21.9816.0863) are used to attach the luminaire to a truss pipe. The Hanging Brackets consist of a pre-assembled bracket with a Mega-Claw Truss Hook. To unpack and attach brackets: Step 1. Unlatch case lid and tilt upward as shown in Figure 2-2. Step 2.
Step 3. Install Hanging Brackets as follows: a. Choose orientation. Brackets may be attached in one of four positions as shown in Figure 2-3. 2-Point Hang 3-Point Hang * * Requires three brackets. Figure 2-3: Hanging Bracket Orientations b. Orient Hanging Bracket in desired direction over two attachment buttons on bottom of upper enclosure (Figure 2-4). c. Place Hanging Bracket down over buttons and slide until bracket locks into place (you will hear a "click" when bracket is locked).
Standard Hang WARNING: The luminaire is heavy. Use caution when lifting. WARNING: One safety cable and at least two truss hooks should be used in all hang configurations. To install in standard 2-point hang: Step 1. Unpack case and attach Hanging Brackets. Refer to "Unpacking and Attaching Hanging Brackets" on page 13. Step 2. Roll case to mounting location as required (Figure 2-5). Step 3. Using two people, carefully lift luminaire into mounting position on truss pipe.
Step 4. Secure in place by tightening Truss Hook wing bolts (Figure 2-6). Ensure that luminaire is fully supported. Step 5. Feed safety cable through base and secure around pipe as shown in Figure 2-6. Step 6. Connect power and data cables according to "Connecting Power and Data" on page 20. NOTE: Mega-Claw Truss Hook is designed to be used only with 2.0" OD round tubing. Safety cable and input pigtail cable must be dressed to avoid interference with luminaire motion. 12.5" (318 mm) 3.
Vertical "Yoke Out" Hang The Best Boy Wash Luminaire can be hung in a vertical position, if required. In this configuration, the luminaire should be positioned so that the interface panel (display) is facing to the side for ease of programming. WARNING: The luminaire is heavy. Use caution when lifting. WARNING: The vertical configuration requires 3 people to hang and secure the luminaire. WARNING: One safety cable and at least two truss hooks should be used in all hang configurations.
Step 3. Roll case to mounting location as required (Figure 2-8). Step 4. Using two people, carefully lift luminaire into mounting position so that display is facing to the side. Step 5. Using a third person, secure in place by tightening Truss Hook wing bolts. Ensure that luminaire is fully supported. Step 6. Feed safety cable through upper enclosure bracket and secure around pipe. Step 7. Connect power and data cables according to "Connecting Power and Data" on page 20.
Standing Position The Best Boy Wash Luminaire can also be used in a standing position. Be sure that the floor or stage will accommodate the load of this moving luminaire. To install in a standing position: Step 1. Unpack case as shown in Figure 2-2 on page 13, but do not remove hanging brackets. (These are not used for standing installations.) Step 2. Carefully remove luminaire from case and place in standing position. Step 3.
Connecting Power and Data The Best Boy Wash Luminaire may be controlled by DMX512 or Ethernet. The control inputs are located at the upper enclosure connector panel. Ethernet DMX512 Thru AC IN 200 -240 VAC THRU COMM ETHERNET DMX WAKE 50 / 60 Hz 12A Max IN DMX512 Input Ethernet Figure 2-10: Data Connections Observe the following guidelines when setting up the system: + A maximum of 32 luminaires may be connected in any one DMX512 or Ethernet data link.
To connect power and data: Step 1. Connect data cable (DMX512 or Ethernet) from console to appropriate input connector at first luminaire in chain (Figure 2-11). Step 2. If required, connect additional data cables from appropriate thru connectors to input connectors of remaining luminaires in chain. Step 3. For DMX512 systems: At last luminaire in chain, install male termination connector at DMX512 THRU connector.
POWER UP AND BASIC SETUP PROCEDURES Powering Up the Luminaire When AC power is applied, the luminaire will begin a calibration sequence which moves its pan, tilt, and all beam control mechanisms. After calibration, the luminaire head will either stop at its "home" position (which positions the pan axis at mid-rotation and the head parallel to the yoke with the lens pointing away from the luminaire upper enclosure) or move to its current DMX-defined position if DMX512 data is present.
Comm LED Operation The Comm LED - located on the upper enclosure connector panel - indicates system control status. This can be used determine if the luminaire is receiving a control signal. LED indications are as follows: Comm LED AC IN 200 -240 VAC THRU COMM ETHERNET DMX WAKE IN 50 / 60 Hz 12A Max Figure 2-13: Comm LED + Green - The Comm LED will light green if there is incoming communication. + Red - The Comm LED will light red if there is no incoming communication.
Setting a Starting Address The method for setting a DMX starting address is the same whether the luminaire is being controlled by DMX512 or Ethernet (Art-Net). The only difference is that the Home screen will display the Comm as either "DMX" or "ETH" depending on the control input. The DMX starting address is programmed at the Menu Touchscreen. The luminaire retains its address even if power is removed.
Ethernet (Art-Net) Comm The starting address for Ethernet (Art-Net) systems can be set from the HOME screen. To program a starting address: Step 1. At Home screen, press address number panel. Step 2. At numeric keypad, enter new starting address and press ENTER. Control Input Type (Ethernet) Figure 2-15: Setting Starting Address (Ethernet Control) To select an Art-Net universe: If using Ethernet control, a universe must be selected in addition to the DMX address.
Starting the Lamp The lamp can be started (turned on) via console command or at the luminaire itself using the Menu Touchscreen. To start lamp using Menu Touchscreen: Step 1. At Home screen, press LAMP panel. Step 2. At Lamp screen, current lamp status (ON/OFF) will be displayed. Press START to bring up YES/NO options. Figure 2-17: Starting the Lamp Step 3. Press YES to start lamp. Step 4. Exit Lamp screen by pressing (X).
Configuring Comm Loss Setting The Communication screen includes a "Comm Loss" setting. This setting will configure how long to wait before the fixture fades to black upon loss of comm data. To configure the Comm Loss setting: Step 1. At Home screen, press COMM panel. Step 2. At Communication screen, press COMM LOSS panel. Step 3. Set Trigger Fade After to No Fade, 30 Seconds or 60 Seconds. Step 4. Exit Communication screen by pressing (X).
Notes 28 BEST BOY® WASH LUMINAIRE USER MANUAL
3. OPERATION This chapter contains instructions for using the menu system and controlling the luminaire by DMX512.
MENU SYSTEM Using the Menu Touchscreen The menu system is a set of software screens used to configure, address, report status, and test the luminaire. These functions are controlled at the Menu Touchscreen as shown in Figure 3-1. COMM Menu Touchscreen Used to configure luminaire address and other options. Also, provides status information and testing.
Menu System Overview The menu system consists of a hierarchy of menu levels. Sub-menus, options, and alpha/numeric keypads may be accessed by pressing the blue and red areas of these main screens. Pressing the right bar (X) while at a sub-menu will return to the previous screen. When power is applied to the luminaire, the Menu Touchscreen will display an initialization screen during calibration. After calibration is complete, the Home screen will be displayed.
Home Screen The Home screen consists of several sections (referred to as "panels") which provide status and configuration information. Pressing the panels on the touchscreen will open the applicable sub-menus. Address (#) The large number (001 in the example screen) is the current DMX address of the luminaire. Press panel to bring up the numeric keypad for editing. Home Screen LAMP + Lamp Status - displays lamp on/off status, hours, and temperatures.
Lamp Screen + Start/Douse - displays current lamp status and power setting. Press START/DOUSE to bring up Yes/No options (depending on current lamp state). + Power On - sets option to strike lamp automatically upon power up. Press to bring up Wait/Start options. + Lamp Hours- displays total lamp hours. Lamp hours are shown in green if under threshold, yellow at 650 hours, and red at 750 hours. It is mandatory that the lamp be changed before 750 hours. Press to bring up Reset Lamp Hours Yes/No options.
Pan/Tilt Screen + Invert Pan / Invert Tilt - displays current invert settings. Press to bring up Invert Yes/No options. When inverted, pan/tilt will move in the opposite direction. + Swap - displays current swap setting. Press to bring up Swap Pan/ Tilt Yes/No options. When swapped, the pan channel will control tilt and vice versa. + Free Mode: Pan & Tilt - displays the current Free Mode setting. (Free Mode allows the luminaire to be used as a follow spot.
Status Screen + Mechanisms - displays mechanism status. Mechanism names will be shown in yellow while calibrating, then change to green if okay or red if an error exists. Locked mechanisms will be shown in white. Press to bring up Test Screen. + Log - displays system status log. Use touchscreen arrows to scroll up or down. Press the log panel itself to scroll all the way back to the most recent log entries. Press CLR to bring up Clear Log Yes/No options.
Test Sub-Menu Screens 36 Recalibrate Screens - Specifies a specific mechanism for recalibration. Disable Screen - Specifies mechanisms to be excluded from tests. Group Tests Screen - Allows multiple luminaires to be tested when daisychained together. Mechanical Tests Screen - Specifies mechanisms to be tested.
DMX512 OPERATION DMX Channel Mapping Table 3-1: Best Boy Wash DMX Channel Mapping Channel 1 Function Description INTENSITY Intensity Adjustment Out Full 2 PAN Pan linear coarse adjustment 0° 615° 3 Pan Fine Pan fine adjustment 4 TILT Tilt linear coarse adjustment 0° 260° 8-Bit home: 0 0 255 home: 127 0 home: 0 home: 127 0 Tilt Fine Tilt fine adjustment home: 0 CYAN Cyan Color Mix home: 0 Open Full Wheel Spin 0-126 Counter-Clockwise 129-255 [Mode: Continuous] Open Full 0 255 0-126 0
Table 3-1: Best Boy Wash DMX Channel Mapping (Continued) Channel Function Description 8-Bit Clockwise 0-126 Fast 0 Slow 126 Stop 127-128 Counter-Clockwise 129-255 Slow Fast 9 10 COLOR MIX CONTROL COLOR TEMPERATURE Sets color mix control mode COLOR 0-9 Spin Cyan 10-19 Spin Yellow 20-29 Spin Magenta 30-39 Spin ALL mixers 40-49 Reserved 50-255 Linear color temperature adjustment OPEN 5 4 1 3 2 Wheel Spin 0 Open 64 4500K 128 3800K 191 [Mode: Continuous, Discrete, Stro
Table 3-1: Best Boy Wash DMX Channel Mapping (Continued) Channel 12 Function Description COLOR CONTROL Sets Designer Wheel control mode Continuous Discrete 13 GOBO 20-39 40-43 Strobe Random - Medium 44-46 Strobe Random - Fast 47-49 Linear Strobe Rate 50-255 Slow 50 Fast 255 Open 1 4 2 3 0-49 0-9 10-19 Gobo 2 20-29 Gobo 3 30-39 Gobo 4 40-49 Wheel Spin Clockwise 50-255 50-150 Fast 50 Slow 150 Stop 151-153 Counter-Clockwise 154-255 Fast GOBO INDEX home: 0 Gobo 1 Slow 1
Table 3-1: Best Boy Wash DMX Channel Mapping (Continued) Channel 18 19 Function Description 8-Bit BEAM IRIS Iris control home: 255 STROBE Small 0 Large 255 Strobe adjustment Open 10-19 Pulse Clockwise 20-39 Fast 20 Slow 39 40 Fast 59 60 Slow 79 MACRO SPEED 80 Fast 99 Slow Random 100-102 Medium Random 103-106 Fast Random 107-109 Speed 110-255 Slow 110 Fast 255 Macro Control home: 0 None 0 Iris - square wave 1 Iris - sine wave 2 Iris - sawtooth 3 Iris - rever
Table 3-1: Best Boy Wash DMX Channel Mapping (Continued) Channel Function 22 FOCUS TIME 23 COLOR TIME 24 IMAGE TIME 25 BEAM TIME 26 CONTROL Description 8-Bit Refer to "Timing Channels" on page 42 home: 255 home: 255 home: 255 Control Channels home: 0 Idle All values must be held for a minimum of 3 seconds to take effect.
Timing Channels Channel Functions Timing channel control improves the timed moves of certain groups of parameters. Four timing channels are provided for this purpose: Focus, Color, Beam, and Image. Timing channels support time values of up to six minutes.
Table 3-3: Timing Channels % Value 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 DMX 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 = Seconds Full Speed 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2 2.2 2.4 2.6 2.8 3 3.2 3.4 3.6 3.8 4 4.2 4.4 4.6 4.8 5 5.2 5.4 5.6 5.8 6 6.2 6.4 6.6 6.8 7.0 7.2 7.4 7.6 7.8 8 8.2 8.4 8.6 8.8 9 9.2 9.4 9.6 9.8 10 10.
Table 3-3: Timing Channels (Continued) % Value 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 44 DMX 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 = Seconds 31 32 32 32 33 33 34 34 34 35 35 36 36 36 37 37 38 38 38 39 39 39 40 40 41 41 41 42 42 43 43 43 44 44 45 45 45 46 46 47 47 47 48 48 49 49 49 50 50 50 51 51 52
Table 3-3: Timing Channels (Continued) % Value 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 DMX 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 = Seconds 150 150 160 160 160 170 170 180 180 180 190 190 200 200 200 210 210 210 220 220 230 230 230 240 240 250 250 250 260 260 270 270 270 280 280 290 290 290 300 300 310 310 310 310 Follows Cue Data BEST BOY® W
Gobo Set Zero Position The Gobo Set Zero command allows adjustment of the gobo wheel’s home position. When this command is issued, the luminaire sets the current wheel position as the "zero" position and stores this offset so it will be retained at the next startup. This allows correction for a sensor that may be slightly out of position causing the gobo wheel to not be perfectly centered and therefore obstructing part of the beam in the open position. To set zero position: Step 1.
4. TROUBLESHOOTING AND MAINTENANCE This chapter provides a basic troubleshooting guide, along with procedures for testing, proper handling, and routine maintenance.
TROUBLESHOOTING Troubleshooting Guide The following table provides a list of common start-up problems and possible solutions. Symptom Solution(s) Refer to... Ensure power cable is properly connected to Neutrik input connector. page 10 Ensure power is switched on at source (mains, disconnect box, etc.) n/a Ensure DMX512 or Ethernet data cable is properly connected. page 20 Ensure DMX512 address setting is correct. page 24 Ensure data cables are correctly configured.
Errors Status Indications The STATUS panel at the Home screen will report overall luminaire conditions as follows: + CALIBRATION (yellow) + OK (green) + ERROR (red) + LOCKED (white) Pressing the STATUS panel will bring up a detailed Status screen as shown below: The Status screen will indicate which specific mechanisms, if any, have errors. It also provides a log of systems activity. The Status screen operates as follows: + Mechanisms - displays mechanism status.
Mechanism Errors Errors will be shown after the mechanism code, for example: PAN:Comm Error.
Other Errors Error Code Explanation Solution Ballast Errors: Parity, Overrun, Bad Header, Msg Too Long Various ballast errors Check ballast comm cable/connections Ballast Heat Sink Over Temp Ballast too hot Check fans Ballast Lamp EOL H/L Voltage Limit Lamp life limit exceeded Check lamp Ballast Line Voltage Low Wrong voltage to strike Check power connection Ballast Short Detected Short circuit on ballast output Check wiring Ballast Timeout: Lamp Strike Lamp failed to strike Check ignite
TESTING Test Screen The Test menu provides options for using the luminaire’s self-test features. + Recalibrate - press to bring up Recalibration Screen. (During recalibration, intensity goes out until all mechanism calibrations are complete and back in position, then fades in.) + Recal All - press to bring up Recalibrate All Yes/No options. + Mech Test - press to bring up Mechanical Tests Screen. (See "Mechanical Tests" on page 53 for more explanation.
Mechanical Tests The Mechanical Tests menu provides a method for exercising all luminaire mechanisms individually. Each mechanism has a similar Test screen. Cyan is shown in the example to the right. The following test functions are available: + Test Chase - The mechanism will move back and forth between two positions. The START/STOP button starts and stops the motion, and the SPEED button sets the rate of the motion.
Group Tests The Group Test menu allows multiple Best Boy Wash Luminaires to be run through a configurable test sequence when chained together via DMX512 or Ethernet. (Refer to "Connecting Power and Data" on page 20 for more information about daisy-chaining.) To perform a group test: Step 1. At Group Test screen, select options to run: Pan/Tilt, Intensity, Colors, Gobos, Zoom, and/or Framing. Step 2.
SOFTWARE UPDATE Software Update Using LumLoader Application Introduction The LumLoader application allows you to update the software in a Best Boy Wash Luminaire. The update will be sent over an Ethernet connection. The luminaire can take the Ethernet input directly, or the update can be translated to DMX512 signal with an appropriate device, either Series 400® or a Virtuoso® Node (with the required software update). The fixtures can be daisy-chained to load multiple fixtures at once.
Troubleshooting + If the LumLoader application does not start up, make sure the Java library is installed. + Make sure the network port is active before starting the application. Sometimes it takes several seconds for the operating system to recognize the network link. + Make sure there is only one instance of the LumLoader application running. + Wireless should be disabled on the computer.
EQUIPMENT HANDLING Proper Lamp Servicing and Operation Servicing + When handling a lamp, hold it by the metal ends while wearing cotton gloves or finger cots. Do not touch the glass envelope (bulb). If you touch the glass with bare fingers, wipe off any fingerprints with alcohol. Heat + When lamps are lit, the interior of the luminaires becomes very hot. To aid in the airflow circulation within the luminaires, after dousing the lamps, wait 5 minutes before removing power to the luminaires.
ROUTINE MAINTENANCE Replacing Lamp Parts: 71.2550.1500 / 2.3749H-03 1 EA LAMP, HTI 1500W/D7/60 OSRAM Tools: Cotton gloves or finger cots Alcohol wipe (supplied with new lamp) WARNING: Remove power from luminaire before performing any maintenance procedures. CAUTION: Refer to "Proper Lamp Servicing and Operation" on page 57 before handling the lamp. CAUTION: Wear cotton gloves or finger cots while servicing lamp.
CAUTION: Allow lamp to cool before servicing.
Adjusting Lamp After a new lamp is installed, the lamp must be aligned to optimize the beam. Adjustment controls are located on the backcap. Tools: #2 Phillips screwdriver optional: 5/16"-1/2" telescoping gauge (http://www.mcmaster.com/#inside-micrometers/=r6gx02 - item # 2081A6) WARNING: Backcap may be HOT during lamp operation. To adjust lamp: Step 1. Power up luminaire and allow to warm up for at least ten minutes. Step 2. Set intensity to 100%. Step 3.
CAUTION: Allow lamp to cool before servicing. Step 5. (Optional) Lamp alignment can be double-checked and/or adjusted by measuring the distance of the lamp plate from the rear door. a. First, open the lamp access door (refer to "Replacing Lamp" on page 58). b. Then use a telescoping gauge tool to measure the distance at three places. These should all be 0.413" as shown in Figure 4-4. Adjust the lamp plate as necessary using the three lamp adjustment screws. c. When finished, close lamp access door. 0.
Removing Head Covers To access some interior head components, one or both of the Head Covers may need to be removed. Parts: 21.9815.0630 2 EA ASSY, HEAD COVER Tools: #2 Phillips screwdriver To remove Head Covers: Step 1. At cover, loosen four captive screws (Figure 4-5). (Cover will still be secured by a safety lanyard.) Step 2. Unclip lanyard to completely remove cover.
Cleaning Intake Filters The filters should be cleaned or replaced when they become dirty. The frequency will depend on how often and in what conditions the luminaire is used. Parts: 10.9815.0661 2 EA 55.9815.0052.0 2 EA HEAD, AIR FILTER, FOAM O-RING, FOAM FILTER RETAINING (as needed) Tools: #2 Phillips screwdriver Compressed air and/or water To clean or replace filters: WARNING: Remove power from luminaire before performing any maintenance procedures. Step 1. Remove power from luminaire. Step 2.
Cleaning Lenses, Frosted Glass, and Front Fresnel Tools & Supplies: (2) Micro Fiber cloths (06.6085.0001.0) OptiMax™ Ultra Pure Cleaning Solution (06.6084.0001.0) Cotton gloves or finger cots #2 Phillips screwdriver 3/16" flat screwdriver To clean lenses, frosted glass, and front fresnel: CAUTION: Use caution when handling lenses and glass. Avoid scratching optical surfaces. CAUTION: Use ONLY OptiMax™ Ultra Pure Cleaning Solution to clean optical components.
Step 3. At TEST menu, press "Clean Lenses." The Cleaning Lenses screen will open. Step 4. Press "Begin" to position lenses for cleaning. Step 5. If lenses are only dusty, use Micro Fiber cloth to carefully wipe lens surfaces. If further cleaning is required, use OptiMax™ Ultra Pure Cleaning Solution and a Micro Fiber cloth to clean. DO NOT use window cleaner! Step 6. Use same technique to clean inside of Frosted Glass. CAUTION: Be extremely careful when removing Front Fresnel in next step.
f. Replace Front Fresnel by doing steps in reverse. Ensure gasket under Front Fresnel is not damaged or missing. CAUTION: Do not handle lenses/ glass with bare hands. Notch Front Fresnel Frosted Glass Note: Ensure gasket under Front Fresnel is not damaged or missing before reinstalling. Retaining Ring Figure 4-8: Cleaning Fresnel and Frosted Glass CAUTION: "Done" MUST BE pressed at the menu to complete the procedure.
Cleaning Luminaire Exterior Tools: Lint-free cloth Window cleaner Vacuum cleaner with brush nozzle or compressed air #2 Phillips screwdriver To clean luminaire: WARNING: Remove power from luminaire before this procedure. CAUTION: Use ONLY OptiMax™ Ultra Pure Cleaning Solution to clean optical components. DO NOT use Window Cleaner on lens! Step 1. Remove power from luminaire. Step 2. Using vacuum cleaner with brush nozzle or compressed air, clean dust from external components.
Replacing Front Fresnel Parts: 42.9815.0110 1 EA FRESNEL LENS Tools & Supplies: 3/16" flat screwdriver Cotton gloves or finger cots WARNING: Remove power from luminaire before performing any maintenance procedures. To replace front fresnel: Step 1. Remove power from luminaire and allow components to cool for at least 5 minutes. CAUTION: Be extremely careful when removing Retaining Ring and Front Fresnel in next step. The lens can be easily chipped or cracked.
Replacing a Gobo Parts: Standard or Custom Gobo(s), as required. (Refer to "Gobo Wheel Configuration" on page 8.) Tools: #2 Phillips screwdriver Hook & Pick tool Cotton gloves or finger cots WARNING: Remove power from luminaire before performing any maintenance procedures. To replace a gobo: Step 1. Remove power from luminaire. Step 2. Rotate Head Assembly so that text on backcap is readable (Figure 4-11). Step 3. Remove Top Head Cover. (Refer to "Removing Head Covers" on page 62.) Step 4.
CAUTION: Do not touch gobos with bare fingers. Wear cotton gloves or finger cots when handling. Step 5. Rotate Gobo Wheel so that desired gobo is accessible (Figure 4-12). Step 6. Rotate gobo to align magnet with alignment mark on sun gear. Step 7. Using hook & pick tool, carefully pull out retaining ring and remove gobo. OPEN GOBO POSITIONS Gobo Sun Gear DETAIL Retaining Ring Gobo Magnet Sun Gear Magnet Alignment Mark Figure 4-12: Replacing a Gobo Step 8.
A. TECHNICAL SPECIFICATIONS + BEST BOY WASH LUMINAIRE + BEST BOY ROAD CASE + AC LINE CURRENT / POWER VS.
Best Boy Wash Luminaire SOURCE: HTI 1500 lamp optics optimized for 60,000 lumens OUTPUT: 60,000+ lumens POWER DRAW: 10.5 Amps at 208V, 8.75 Amps at 240V. Auto-sensing voltage input range is 170V to 270V. POWER FACTOR: 0.
12.5" (318 mm) 3.88" (99 mm) 29" (736 mm) 38.5" (978 mm) 5.78" (147 mm) 34.8" (884 mm) 19.15" (486 mm) 24.0" (610 mm) 28.6" (726 mm) 27.4" (696 mm) 16.75" (425 mm) 19.0" (483 mm) 31.0" (787 mm) 28.6" (726 mm) 11.
Best Boy Road Case EMPTY WEIGHT: 171 lbs (77.56 kg) LOADED WEIGHT: 389 lbs (176.45 kg) 24" (610 mm) 52" (1321 mm) 39.5" (1003 mm) 33.8" (859 mm) 21" (533 mm) 12.
AC Line Current / Power vs. Voltage TEST VOLTS FREQ AMPS VA POWER PF 1 170 50Hz 12.53 2130 2124 0.997 2 180 50Hz 11.79 2122 2115 0.996 3 200 50Hz 10.56 2110 2100 0.995 4 200 60Hz 10.53 2106 2096 0.995 5 210 60Hz 10.01 2104 2091 0.994 6 220 50Hz 9.56 2103 2088 0.993 7 230 50Hz 9.13 2100 2083 0.992 8 240 50Hz 8.74 2098 2080 0.990 9 240 60Hz 8.74 2098 2078 0.990 10 250 50Hz 8.38 2095 2074 0.989 11 260 50Hz 8.06 2093 2065 0.
Photometric Data Narrow Field of View 76 BEST BOY® WASH LUMINAIRE USER MANUAL
Medium Field of View BEST BOY® WASH LUMINAIRE USER MANUAL 77
Wide Field of View 78 BEST BOY® WASH LUMINAIRE USER MANUAL
B. GLOSSARY This glossary provides useful terms associated with operating the Best Boy Wash Luminaire.
Glossary of Terms 8-Bit DMX The universally accepted lighting control protocol in the entertainment industry. A console uses this protocol to control specific devices in a lighting system. A DMX512 channel packet is eight bits of absolute parameter data. 8-bit refers to the resolution of the signal: 256 step resolution, providing channel values from 0 through 255. A DMX512 data packet is a group of 512 data channels.
Douse To de-energize a luminaire lamp. (Douse is unrelated to intensity states.) Ethernet Networking technology used to connect local area networks (LANs) via CAT5 cable or wireless. Fixture Orientation Based on the direction the pigtail points as it exits the fixture. Flipped Focus When one or more fixtures inadvertently move differently from others in the system. Focus The point to which the light beam is directed.
Reply Digital data signals transmitted from each luminaire to the console. Only one luminaire may transmit at a time, in response to a request from the console. Signal Control protocol from a lighting console or interface. Splitter (Isolator) Device used to optically isolate and split a DMX512 signal. Note: A DMX "two-fer" cannot be used to divide a signal. Start To energize a luminaire arc lamp (applies to arc-lamp luminaires only).
Best Boy® Wash Luminaire User Manual Version as of: April 14, 2014 PRG part number: 02.9815.
