Model 4069 ProfileIR
TM
User Manual Specifications
Research, Inc. 5
6.2 gpm (23.4 lpm) 4.2 gpm (15.9 lpm) 2.7 gpm (10.2 lpm) 1.7 gpm (6.4 lpm) Water Flow Requirement
103390-010 103390-007 103390-005 103390-003 Lamp Type
639 lb (290 kg) 588 lb (267 kg) 550 lb (267 kg) 523 lb (237 kg) Weight *
82 amp 55 amp 69 amp 43 amp Max Current
480 volt 3 phase 480 volt 3 phase 240 volt 3 phase 240 volt 3 phase Voltage
68.4 kW 45kW 28.8kW 18 kW Power Generated
4069P-18R-38L 4069P-18R-25L 4069-18R-16L 4069P-18R-10L Model
Single Chamber 4 Inch Diameter Profile
3.4 gpm (12.8 lpm) Water Type Flow Requirement
103390-003 Lamp Type
619 (28 kg) Weight *
43 amp Max Current
480 volt 3 phase Voltage
36kW
4069P-18R-10L-Dual
Power Generated
Model
Dual Chamber 4 Inch Diameter Profile
4 Inch Diameter ProfileIR Model 4069P
4.2 gpm (15.9 lpm) 2.8 gpm (10.6 lpm) 1.8 gpm (6.8 lpm) 1.2 gpm (4.5 lpm) Water Flow Requirement
103390-010 103390-007 103390-005 103390-003 Lamp Type
564 lb (256 kg) 535 (243 kg) 515 lb (234 kg) 501 lb (227 kg) Weight *
55 amp 36 amp 46 amp 29 amp Max Current
480 volt 3 phase 480 volt 3 phase 240 volt 3 phase 240 volt 3 phase Voltage
45.6kW 30kW 19.2kW 12kW Power Generated
4069P-12R-38L 4069P-12R-25L 4069-12R-16L 4069P-12R-10L Model
Single Chambe
r
2 Inch Diameter Profile
2.4 gpm ( 9 lpm) Water Type Flow Requirement
103390-003 Lamp Type
575 lb (26 kg) Weight *
30 amp Max Current
480 volt 3 phase Voltage
25Kw
4069P-12R-10L-Dual
Power Generated
Model
Dual Chamber 2 Inch Diameter Profile
2 Inch Diameter ProfileIR Model 4069P
