Manual

Model 4069P ProfileIR
TM
User Manual Contents
Section page
INTRODUCTION
General Description 1
Standard Features 1
Optional Features
2
SAFETY
General 3
Gas Shock 3
High Temperatures 3
Electrical 3
SPECIFICATIONS
Specifications 4
Dimensions 6
INSTALLATION
Wiring 8
Control Connections 10
Remote Interlock Switch 10
Remote Fast Stop 10
Water Connections 10
Air Connections
10
OPERATION
Main Disconnect Switch 11
Operator Control Panel 12
Panel View Terminal 13
Main Screen 14
Recipe Screen
16
Alarms Screen 18
Options Screen
20
MAINTENANCE AND
TROUBLE SHOOTING
Routine Maintenance 22
Lamp Removal, Replacement and Installation
22
Split Quartz Cleaning and Replacement
24
