Use and Care Manual

– 3 –

When the tank is full.

1. Release drain hose from hose clamp.

2. Remove plug from hose end to start draining process.

3. When draining is complete, replace hose plug and snap hose back

into clips on side of tank.

NOTE: When the water level in the tank exceeds the safety level, the

safety device will automatically block the inlet, and the motor turning

sound will be changed, but power will remain ON. The power must be

turned OFF before emptying the tank.

The paper filter must be removed for wet recovery.

Push the metal ping counterclockwise to release the filter.

Remove the paper filter.

The hose and swivel connector are pre-assembled at the factory.

To attach the swivel connector to the intake fitting of the canister:

1. Push the grooved cuff straight into the intake fitting.

2. To remove, press the release button on top of the intake fitting

while pulling the grooved cuff out.

To dismantle, unclip both latches and remove top housing and filter

with frame.

ash the filter with water and allow it to dry

3. After washing, remove excess water with a gentle squeegee.

4. Replace the filter and top housing and fasten the latches.

NOTE: This cleaner is designed with a powerful suction. Do not be

alarmed if the motor noise increases when performing tougher

cleaning work.

MAINTENANCE AND SER

VICING

HOSE ATTACHMENT INSTRUCTIONS

REMOVE THE PAPER FILTER

DRAINING

Model PF54 drain hose.

Model PF54 shown with optional front mounted squeegee.
