User's Manual

Troubleshooting Wideband Radio Head
4-4 044-05251 Rev A
22 External
alarm 2
External Config External alarm input EA2 active more than 1 second.
Ceasing External alarm input EA2 no longer active.
23 External
alarm 3
External Config External alarm input EA3 active more than 1 second.
Ceasing External alarm input EA3 no longer active.
24 External
alarm 4
External Config External alarm input EA4 active more than 1 second.
Ceasing External alarm input EA4 no longer active.
30 No
modem
found
Remote
ctrl
None No modem found, that is no answer is returned on a
poll string to the modem.
33 No con-
nection
Remote
ctrl
None No connection at callback. The WRH has tried to call
as many times as stated in the alarm call settings. No
connection was established.
Warning No connection at alarm call. The WRH has tried to
call as many times as stated in the alarm call settings.
No connection was established. This alarm does not
generate a new attempt to report alarm by alarm call.
34 Login
failed
None Invalid WRH password.
35 Remote
connec-
tion
Remote
ctrl
None Modem connection to OM-Online opened. Not logged
on CU2. Login Registry gives the same function and
more information about CU2.
36 Modem
init failed
Remote
ctrl
None Initiation string to modem not OK. The initiation string
sent to the modem is not OK. The string may contain
commands not recognized by the modem. An alarm
might be sent anyway. Suggested remedy: Check the
modem using the OM-Online or OMS modem debug-
ger.
37 Remote
timeout
Remote
ctrl
Warning The time limit of 20 minutes is exceeded without
extending the timer. The modem connection is termi-
nated by the WRH.
38 PIN code
failed
Remote
ctrl
Warning The PIN code sent to MS is incorrect. To unlock the
MS/SIM card, the PUK code will probably be needed.
Ceasing The cause of the alarm has ceased.
39 No phone
detected
Remote
ctrl
Warning When using a PC-card together with the MS, the
alarm indicates contact with the PC-card, but MS is
not present or turned off. Note: A Nokia MS does not
power-up after power failure. Suggested remedy:
Ensure the cellular phone is connected.
Ceasing The cause of the alarm has ceased.
40 Battery
fault
RCU,
FON
charger
Error The backup battery on the RCU or the FON PCBA
does not work properly. Suggested remedy: Check
cables or replace battery.
