G3L-2100-30-B/G3L-2100-30-C Operation Manual
1-6 Functional And Physical Specifications
Functional and physical specifications for the model G3L-2100-30-B and G3L-2100-30-C amplifi-
ers are listed in appendix A.
1-7 Equipment Changes
Powerwave Technologies, Inc. reserves the right to make minor changes to the equipment, in-
cluding but not necessarily limited to component substitution and circuitry changes. Changes that
impact this manual may subsequently be incorporated in a later revision of this manual. To that
end, we ask that you, our customer, share with us any information acquired in field situations that
would enhance this manual.
1-8 Ordering Information
Table 1-7 below gives the model numbers and descriptions used when ordering major compo-
nents.
Table 1-7 Major Components
Nokia Model
Number*
PWAV Model Num-
ber*
Manual Number Description
WPAA G3L-2100-30-B 044-05133 30W, 2110 – 2170 MHz amplifier
module (DC)
WPAB G3L-2100-30-C 044-05133 30W, 2110 – 2170 MHz amplifier
module (AC)
* Nokia model number located on front panel. Powerwave Technologies model number located
on rear panel.
