Output Voltage & Current Ratings
MODEL OUTPUT VOLTAGE OUTPUT CURRENT MAX OUTPUT POWER
PSGE30-05-(XX) 5.0V DC 6.00A 30 Watts
PSGE40-12-(XX) 12V DC 3.33A 40 Watts
PSGE40-15-(XX) 15V DC 2.67A 40 Watts
PSGE40-16-(XX) 16V DC 2.5A 40 Watts
PSGE40-18-(XX) 18V DC 2.22A 40 Watts
PSGE40-24-(XX) 24V DC 1.67A 40 Watts
PSGE60-15-(XX) 15V DC 4.00A 60 Watts
PSGE60-16-(XX) 16V DC 3.75A 60 Watts
PSGE65-12-(XX) 12V DC 5.42A 65 Watts
PSGE65-18-(XX) 18V DC 3.61A 65 Watts
PSGE65-24-(XX) 24V DC 2.71A 65 Watts
NOTE: (XX) in part number denotes output connector type. Standard stock items have 2.5 x 5.5 x 11mm centre positive barrel
connector. Therefore part number would be PSGE40-12-02. Other connectors are available which would be a different 2 digit number,
consult sales office for details. Other output voltages also available consult sales office for details.
Mechanical Details
Desk Top Power Supplies
Weight 280 grams (approx)
Dimensions in mm
Note: PSGE30-05 dimensions are 111 x 52 x 32mm
