POWER SMART DB5023 PARTS LIST

Exploded

View No.

Parts Decription Parts No. Quantity

1 Bilt 8SFDD06-45D 2

2 space for switch box

3 Screw 8SJAC40-16D 3

4 right switch housing 8454-501302 1

5 switch 8042-501301 1

6 spring 8044-501303 3

7 switch fixing plate 8044-501303 1

8 pin 8086-501301 1

electric cable（120v)

8342-501301 1

10 Connections components 8422-501303 1

11 switch button 8312-501301 1

12 screw 8SJAC40-8D 1

13 washer 8WF-0501602D 1

14 left switch housing 8454-501301 1

15 hex lock nut 8NG-06D01 2

16 safety key 8043-501301 1

17 switch trigger 8044-501303 1

18 handle bar 8044-501301 1

19 sleeve for switch extension bar

20 upper tube 8061-501301 1

21 T bolt 8206-501001 2

22 washer 8WF-082202D 2

23 M8 nut 8313-501301 2

24 hex lock nut M8 8NA-08D01 2

25 Middle tube 8061-501302 1

26 screw ST6X35 8SJAA60-35D 4

27 Lower tube 8061-501303 1

28 T bolt 8206-501001 2

29 hex lock nut M8 8NA-08D01 2

30 M8 nut 8313-501301 2

31 washer 8WF-082202D 2

32 Cotter pin 8CC-10B 1

33 washer 8WF-102202D 1

34 screw 8SJAC40-14D 3

35 hex lock nut M6 8NG-06D01 2

36 washer 8WF-061301D 2

37 screw 8SJAC40-14D 1

38 screw 8SJAC40-12D 1

39 Left wheel bracket 8292-501301 1

40 Hex bolt 8SFDD06-30D 2

41 Spacer 8334-501003 1

42 Wheel 8121-501101 1

43 Washer 8WF-102202D 1

44 Cotter pin 8CC-10B 1

45 Wheel axile 8081-501302 1

46 Cotter pin 8CC-10B 1

47 Washer 8WF-102202D 1

48 Wheel 8121-501101 1

49 Spacer 8334-501003 1

50 Hex bolt 8SFDD06-30D 2

51 BT4×14screw 8SJAC40-14D 1

52 BT4×12screw 8SJAC40-12D 1

53 Right wheel bracket 8292-501306 1

54 Washer 8WF-061301D 2

55 Hex lock nut 8NG-06D01 2

56 Washer 8WF-102202D 1

57 Cotter pin 8CC-10B 1

58 screw 8SJAC40-14D 3

59 Cable clip 8429-501102 1

60 Cable clip 8281-501101 3

61 M6×20screw 8SJAD04-20D 2

62 Nut

63 Motor keeper 8186-500101 2

64 BT4×16screw 8SJAC40-16D 4

65 Housing 8020-501301 1

66 Belting

67 Spiral line pressing cap 8410-501101 1

68 Over-load protection 8444-501002 1

69 BT4×14screw 8SJAC40-14D 1

70 Motor keeper 8186-500101 1

71 BT4×14screw 8SJAC40-14D 2

72 BT4×10screw 8SJAA30-10D 4

73 Carbon plate 8202-501201 2

74 Brush cover 8407-501202 2

75 Electrical carbon 8406-501203 2

76 Brush supporter 8409-501201 2

77 ST4×70screw 8SBAA40-70D 2

78 Rear motor bracket 8292-501006 1

79 Bearing 608ZZ 8C-082207-ST01 1

80 Stator 8405-501103 1

81 Steel gasket 8341-501001 1

82 Damping plate 8208-501201 2

83 BT4×16screw 8SJAC40-14D 4

84 Motor keeper 8186-501201 1

85 Front motor bracket 8292-501005 1

86 Rotor 8402-501103 1

87 Bearing 6001ZZ 8C-122808-ST01 1

88 Cover 8023-501001 1

89 BT4×25screw 8SJAA50-25D 1

90 Gear 8123-501001 1

91 Nut left spin 8NA-08D02 1

92 Spring 8342-501101 1

93 Washer 8WF-041201D 1

94 Washer 8WS-04D01 3

95 M4×10screw 8SJAD04-10D 1

96 ST4×35screw 8SBAA40-35D 3

97 BT4×16screw 8SJAC40-16D 3

98 Bearing 608ZZ 8C-082207-ST01 1

99 Ring 8CC-10B 1

100 Gear 8123-501002 1

101 Key 8205-501201 1

102 Shaft 8085-501001 1

103 Bearing 6201ZZ 8C-123210-ST01 1

104 Steel gasket 8341-501201 2

105 Cover 8081-501003 1

106 ST4×40screw 8SBAA40-40D 2

107 M4×14screw 8SJAD04-14D 3

108 Washer 8WS-04D01 3

109 Washer 8WF-0400801D 3

110 Pulley bracket 8181-501201 1

111 M4×10screw 8SJAD04-14D 3

112 Washer 8WS-04D01 3

113 Washer 8WF-0501201D 3

114 Pulley 8121-501002 1

115 Bearing 6000Z 8C-102608-ST01 1

116 Washer 8WF-051602D 1

117 M4×10screw 8SJAD04-14D 3

118 Pulley 8122-501101 1

119 BT4×14screw 8SJAC40-14D 6

120 Upper housing 8006-501302 1

121 BT4×14screw 8SJAC40-14D 4

122 Right cover 8020-501302 1

123 Belt 8345-501301 1

124 Base 8006-501301 1

125 Nut left spin 8NA-08D02 1

126 Pulley 8122-501001 1

127 Hex bolt 8SFDD06-20D 3

128 Washer 8WS-06D01 3

129 Bearing coupler 8145-501201 1

130 Bearing 6202Z 8C-153511-ST01 1

131 Roller fixed plate welded together 8187-501305 1

132 Roller Spindle 8440-501301 1

133 Left scraper assembly 8321-501303 2

134 M6×20screw 8SJAD06-20D 4

135 Washer 8WF-061602D 4

136 Hex lock nut 8NG-06D01 4

137 Scraper 8321-501302 2

138 M6×20screw 8SJAD06-20D 4

139 Washer 8WF-061602D 4

140 Hex lock nut 8NG-06D01 4

141 Right scraper assembly 8321-501304 2

142 M6×20screw 8SJAD06-20D 4

143 Washer 8WF-061602D 4

144 Hex lock nut 8NG-06D01 4

145 Right cover 8020-501303 1

146 Roller fixed plate welded together 8187-501305 1

147 Bearing 6202Z 8C-153511-ST01 1

148 BT4×14screw 8SJAC40-14D 4

149 Bearing coupler 8145-501201 1

150 Bolt 8SFDD06-20D 3

151 Washer 8WS-06D01 3

152 BT4×20screw 8SJAC40-20D 3

153 Scraper 8181-501301 1

154 BT4×20screw 8SJAC40-20D 3

155 Plate 8186-501302 1

156 Chute direction 8087-501301 1

157 Spring 8324-603101 1

158 snow cover 8020-501304 1

159 Chute 8104-501302 1

160 Hex lock nut M8 8NA-08D01 2

161 M8 knob 8313-501301 2

162 Rubber pad 8202-501301 2

163 Carriage bolt 8SBJD08-25D 2

164 Chute 8104-501301 1

165 BT4×14screw 8SJAC40-14D 1

166 Washer 8WF-0501201D 1

167 Crank connection 8087-501307 1

168 Shaft 8086-501302 1

169 Crank connection 8301-501001 1

170 rivet

171 Crank 8087-501401 1

172 M4×16screw 8SEAD04-16D 1

173 Nut 8NG-04D01 2

174 Crank 8331-501002 1

175 Washer 8WF-061201D 1

176 Hex lock nut 8NG-06D01 1

177 Eye bolt 8204-501003 1

178 Upper crank 8087-501301 1

179 Crank handle 8001-501301 1

180 Washer 8WF-061601D 1

181 Washer 8CC-8B 1

182 Sponges tube

183 handle bar 8020-501305 1

184 screw

185 screw

186 Cotter pin
