Installation Guide

5
4.
Lowes.com/
p
ortfolio
ASSEMBLY INSTRUCTIONS
Remove preassembled finial (B) from harp (C).
Attach fabric shade (A) to harp (C), securing with
finial (B). Then install bulb (K) into table lamp assembly.
Repeat steps 1 - 4 for second table lamp.
CAUTION:
When replacing bulb, please
allow bulb to cool down before touching.
Remove preassembled cap from end of power cord
and plug power cord into wall outlet.
NOTE: Use preassembled switch on switch
assembly (E) to turn lamp ON/OFF.
If light does not function, please refer to
TROUBLESHOOTING on next page.
4
A
B
2.
Place fabric shade (A) on a flat, clean surface with
the preassembled spider fitter side down. Place side
support (D) inside fabric shade (A) so one of the
arms on the spider fitter is positioned at middle of
side support (D).
Note: Make sure to turn side support (D) so the
curve of side support (D) fits along the curve of the
fabric shade (A).
Raise fabric shade (A) and insert the ends of side
support (D) into holes along the frame at bottom of
fabric shade (A). Ensure the ends have been
inserted completely.
Repeat for the remaining two side supports (D).
3.
A
D
Holes
3
2
Curved Side
Spider Fitter
A
D
D
A
Switch
Hg
LAMP CONTAINS MERCURY
Manage in accordance with Spills, Disposal and Site Cleanup
Requirements. In case of breakage, follow clean-up
procedures provided by contacts below.
www.epa.gov/cflcleanup
1-866-284-4010
K
