User Manual V
2
IU 4350 Converged Network Appliance
3 - 38
This page includes the following areas:
The H.323 Neighboring page includes the following buttons:
Item Description
Prefix Routing
and
Gatekeeper
Neighboring
table
Lists rules for forwarding incoming calls based on their dialed
alias.
Rules are executed in the order in which they are listed. Use the
arrows to move entries up and down, or use the Index field to
specify where a new or edited rule falls in the list.
Add a prefix Allows you to add new prefixes to the Prefix Routing and
Gatekeeper Neighboring table.
Item Description
Action Indicates whether the rule is to be added or edited.
Prefix Specifies the prefix pattern to be matched against the dialing
string. See
<l_link>“Regular Expressions” on page 39 for details
on valid patterns.
Index Determines the order in which the rule is scanned in the Prefix and
Gatekeeper Neighboring table. To add a rule between two rules
with consecutive indexes (n and m), use the higher index (m).
Strip Indicates whether the matching prefix is stripped from the dialing
string.
Add Specifies a string to be prepended to the dialing string.
Neighbor Determines whether a location request (LRQ) is sent when this
prefix matches.
• If enabled, the prefix becomes a neighboring statement.
• If disabled, the incoming Q.931 Setup is forwarded to the given
address without a preceding LRQ.
This field is used for interoperability with other gatekeepers that
may not accept a Setup without a preceding LRQ.
Local Zone Provides compatibility with remote gatekeepers that are
configured to accept LRQs only from sources that match its
configured remote zone. If a gatekeeper is configured to accept
requests only from a known source, enter the zone in this field.
Address Specifies the IP address or domain name of the device to which
the call is to be forwarded.
Item Description
Commit Applies the settings configured on this page.
Reset Clears all fields and selections and allows you to enter new
information.
