- RMX® 2000 Installation & Configuration Guide
- General Safety Precautions
- Preparations
- Unpacking the RMX
- Management Network Configuration on the USB Key
- Installing the RMX
- First Entry Power-up
- Product Registration and Activation Key Retrieval
- 1 Using a Web browser, connect to http://portal.polycom.com.
- 2 Login with your Email Address and Password or register as a new user.
- 3 Select the Product Registration link.
- 4 Follow the on-screen instructions for Product Registration and Product Activation. (The RMX’s serial number is on a sticker on the back of the unit, if needed.)
- 5 Write down the Product Activation Key number or copy it for later use.
- Connecting to the MCU
- 1 Start the RMX Web Client application on the workstation by entering in the browser’s address line the IP Address of the control unit as defined in the USB key in the format: http://
and pressing Enter. - 3 In the Activation Key field, enter or paste the Product Activation Key retrieved earlier and click OK.
- 1 Start the RMX Web Client application on the workstation by entering in the browser’s address line the IP Address of the control unit as defined in the USB key in the format: http://
- Configuring the IP Network Service
- 1 In the Fast Configuration Wizard - IP dialog box, define the following parameters:
- 2 Click Next.
- 3 In the Fast Configuration Wizard - Routes dialog box, enter the IP address of the default router.
- 4 Click Next.
- 5 Enter the required DNS information in the dialog box.
- 7 In the Fast Configuration Wizard - Environment dialog box, select the IP Network Type: H.323, SIP or H.323 & SIP.
- 8 Click Next.
- 11 Click Next.
- 13 In the Fast Configuration Wizard - SIP dialog box, enter the following information:
- 15 Enter the required Security information in the dialog box.
- 16 Click the Save & Continue button.
- 17 Define the following parameters:
- 18 Click Next.
- 19 In the PRI Settings dialog box, define the following parameters:
- 20 Click Next.
- 21 In the Span Definition dialog box, define the following parameters:
- 26 Optional. Repeat steps 23 to 25 to define additional dial-in ranges.
- 27 Enter the MCU CLI (Calling Line Identification).
- 28 Click Save & Continue.
- After clicking Save & Continue, you cannot use the Back button to return to previous configuration dialog boxes.
- The Spans dialog box opens displaying the following read-only fields:
- 31 Click Next. The System Flags dialog box is displayed.
- 32 In the Fast Configuration Wizard - System Flags dialog box, enter the following information:
- 33 Click Save & Close. The RMX confirms successful configuration.
- 34 In the Success Message box, click OK.
- 35 In the Reset Confirmation dialog box, click Yes.
- User Definition
- To add a new user to the system:
- 1 In the RMX Management pane, click the Users option. The Users pane appears.
- 2 Click the New User button or right-click anywhere in the pane and then click New User.
- 3 In the User Name text box, enter the name of the new user. This is the login name used by the user when logging into the system.
- 4 In the Password text box, enter the new user’s password. This will be the user’s password when logging into the system.
- 5 In the Authorization Level list, select the user type which determines the application display and functionality.
- 6 Click OK.
- To delete a user from the system:
- To add a new user to the system:
- Selecting the RMX Web Client Languages
- Conferencing Entities
- Connecting to a Conference Directly or via Entry Queue
- Conference Control Using DTMF Codes
2
If ISDN/PSTN is installed in your conferencing environment, obtain the
following information from your ISDN/PSTN Service Provider:
• Switch Type, Line Coding and Framing, Numbering Plan and
Numbering Type
• Dial-in number range
Unpacking the RMX
1 When you receive the RMX 2000 packing case, inspect the
equipment for damage and verify that the components match the
packing slip.
2 Open the top cover of the RMX 2000 packing case and make sure
that the Installation Accessories kit contains the power cables and a
USB Key.
3 Remove the top cover, lift the RMX 2000 from the package and
place it on a flat surface.
Management Network Configuration on the
USB Key
The system is shipped with the following default IP addresses:
• Control unit IP address – 192.168.1.254
• Shelf Management IP Address – 192.168.1.252
• Control unit subnet mask – 255.255.255.0
• Default Router IP Address – 192.168.1.1
If the RMX is connected to the public ISDN Network, an external
CSU or similar equipment is needed.
Write down the RMX’s serial number that is on a sticker on the back
of the unit. It will be needed for product registration later in the
installation process.
