RMX 2000 Rear Panel LEDs
RTM IP
The following LEDs appear on the RTM IP card:
Table 1-7 RMX 2000 RTM IP LEDs
Component
LED
Name
LED Color Description
LAN LEDs (1-3) LNK Green ON with an active network
connection, flickers with Packet
activity.
1 Gb Amber ON with a 1Gb online
connection, flickers with Packet
activity.
10/100 ShMG
LEDs
LNK Green ON with an active network
connection, flickers with Packet
activity.
100 Amber ON when the active network is
10/100Mb, flickers with Packet
activity.
SLOT (1-4)
LEDs
LNK (1-4) Green ON with an active network
connection, flickers with Packet
activity.
1Gb (1-4) Amber ON with a 1Gb online
connection, flickers with Packet
activity.
