Status Messages
Status Display
The call status can be displayed in a number of ways. The getcallstate
command on page 4-153 returns a table listing the status, speed, and dialed
number of current calls.
To display real-time status on individual B channels (incoming or outgoing
calls), either register the API session with the callstate command on page 4-64,
or start an outbound call with the dial command on page 4-93. These two
commands will cause the system to re-direct the B channel status messages to
the session which has issued one of these two commands. For example, if the
RS-232 device issues a
dial command, then call status is directed to the RS-232
port; if a later session on a Telnet port issues a
dial command, then call status
is also directed to that Telnet port.
B Channel Status Message Example
The following output example is for B channel status messages, where:
cs Indicates call status for one B channel.
RINGING Indicates a ring-in or ring-out and is equivalent to a 25% blue
sphere on the graphical user interface.
CONNECTED Is equivalent to a 50% yellow sphere.
BONDING Indicates the bonding protocol is operational on the channel and
is equivalent to a 75% orange sphere.
COMPLETE Is equivalent to a 100% green sphere.
