Loudspeaker Catalog
CENTER CHANNEL
LOUDSPEAKERS CSi A6 CSi A4
Driver Complement 2 - 6 1/2" (16.5cm) Polymer Composite Dynamic 2 - 5 1/4" (13.3cm) Polymer Composite Dynamic
Balance with rubber surround, Balance with rubber surround,
1 - 1" (2.5cm) Silk Polymer Dome Tweeter 1 - 1" (2.5cm) Silk Polymer Dome Tweeter
Frequency Response: Overall / -3dB Limits 45Hz - 27kHz / 55Hz - 26kHz 55Hz - 27kHz / 65Hz - 26kHz
Impedance compatible with 8 Ohm outputs compatible with 8 Ohm outputs
Recommended Amplification 20 - 200 Watts/channel 20 - 180 Watts/channel
Efficiency 90dB 89dB
Magnetically Shielded yes yes
Available Finish black oak or cherry veneer black oak or cherry veneer
Dimensions 7 3/4" H x 24" W x 14" D 6 7/8" H x 20" W x 8 3/4" D
19.68cm H x 60.96 cm W x 35.56 cm D 17.46cm H x 50.80cm W x 22.23cm D
Features vented with dual PowerPort vented with dual PowerPort
and single ARC Port and single ARC Port
SURROUND
LOUDSPEAKERS F/XiA6 F/XiA4
Driver Complement 1 - 6 1/2" (16.5cm) Polymer Composite Dynamic 1 - 5 1/4" (13.3cm) Polymer Composite Dynamic
Balance with rubber surround, Balance with rubber surround,
2 - 1" (2.5cm) Silk Polymer Dome Tweeter 2 - 1" (2.5cm) Silk Polymer Dome Tweeter
Frequency Response: Overall / -3dB Limits 45Hz - 27kHz / 55Hz - 26kHz 50Hz - 27kHz / 60Hz - 26kHz
Impedance compatible with 8 Ohm outputs compatible with 8 Ohm outputs
Recommended Amplification 20 - 150 Watts/channel 20 - 150 Watts/channel
Efficiency 88dB 88dB
Available Finish black or white black or white
Dimensions 14 3/4" H x 13 3/8" W x 8 5/8" D 12" H x 11 3/8" W x 7 7/16" D
37.47cm H x 33.97cm W x 21.91cm D 30.48cm H x 28.89cm W x 18.89cm D
Features vented with single port vented with single port
SURROUND
LOUDSPEAKERS OWM3
Driver Complement 1 - 4 1/2" (11.4cm) Dynamic Balance Driver; 1 - 1" (2.5cm) Silk Dome Tweeter
Frequency Response: Overall / -3dB Limits 80Hz - 25kHz / 100Hz - 24kHz
Impedance 4 Ohms
Recommended Amplification 20 - 100 Watts
Efficiency 89dB
Continuous Power 100 Watts
Dynamic Power 200 Watts
Available Finish matte black (paintable) or matte white (paintable)
Product Weight / Shipping Weight 4.4 lbs with stand each / 10.28 lbs pair
(2.0 kg with stand each / 4.66 kg pair)
Dimensions 10" H x 7"Wx4"D(25.4cm H x 17.8cm W x 10.4cm D without stand)
10" H x 7" W x 4 11/16" D (25.4cm H x 17.8cm W x 11.9cm D with stand)
* Magnetically shielded components for safe placement near TVs or video monitors.
We’re fanatics when it comes to providing you useful, accurate information that can help you evaluate our products. But as we all know, we live in an imperfect world. At least some of us do.
That’s why performance specifications and product dimensions are subject to change without notice. For the most current specifications see our website, www.polkaudio.com/home.
