USER MANUAL LCD HDTV KF SERIES

50 5mm.

13 8mm.

丝印430C

KF271

VOL. VOL. CH. CH. MEN U SOURC E

5mm 5mm

10 mm

Chapter 3 Using the LCD TV

The PIP/POP feature allows simultaneous viewing of video from two sources (TV, VCR, DVD etc).

Only one source’s audio is played at a time; the user may select which source’s audio is heard.

 Press the PIP button once to enter picture in picture mode.

Main

Sub

MAINSUB

Using Picture-In-Picture

▪ Press ◄ ► to toggle the audio source between the main window and

the sub window.

▪ Press the OK button to change the position of the second window.

▪ Press ◄ ► to activate either the main or sub window, then press the Source

button to display the Input List:

Sub

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR) 

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

COMPUTER (VGA)

▪ Press ▲▼ to change input source and press the OK button.

Chapter 3

USING THE FEATURES
