Owner's manual

TRAILER HITCH
This vehicle is equipped with a receiver hitch bracket for a trailer hitch and trailer
towing equipment.
NOTICE
To avoid injury and property damage, always heed the warnings and towing
capacities outlined in the specification table.
Whenever the vehicle is towing, always stay clear of the area between the
vehicle and the towed object.
REAR HITCH
Use the rear hitch for towing a trailer.
REAR HITCH SPECIFICATIONS
Material ASTM A 1
Fasteners Metal pin with security cotter pin
Weld Length and Positions 7 mm fillet, all around
Maximum Vertical Load 100 kg applied on coupling point
Maximum Towable Mass 1000 kg
Approval # E9-55R-01.6126 / E20-55R-01 3487
REAR HITCH CERTIFICATION LABEL
The hitch certification label is located near the hitch on models equipped with a
factory-installed rear hitch.
39
FEATURES AND CONTROLS
