Owner's manual

SPECIFICATIONS
POLARIS GENERAL 1000 EU / ABS / ZUGMASCHINE
Gross Vehicle Weight (includes weight of
operator, passenger, cargo, accessories)
1268 kg
Dry Weight 704 kg (EPS)
719 kg (EPS Deluxe)
720 kg (ABS)
722 kg (ZUG)
Test GVW - Rollover Protection System (ROPS) 1268 kg per OECD Code 4 procedure
Fuel Capacity 36 L
Engine Oil Capacity 2.4 L
Coolant Capacity 5.1 L
Towing Capacity 680 kg
Hitch Tongue Capacity 68 kg
Max. Cargo Box Load* 272 kg
Overall Length 294.6 cm (EPS)
299.7 cm (EPS w/Winch and Aluminum Wheels)
299.7 cm (EPS Deluxe)
Overall Width 156.2 cm
Overall Height 193 cm
Wheelbase 205.7 cm
Cargo Box Dimensions (Inside) 66 x 109 x 28 cm
Ground Clearance 30.5 cm
Min. Turning Radius 483 cm
Engine 4-Stroke DOHC Twin Cylinder
Displacement 999 cc
Bore x Stroke 93 mm x 73.5 mm
Alternator Output 560 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System Electronic
125
SPECIFICATIONS
