Power Cable Connections and Switching the Power On/Off
RGB
STANDBY
VIDEO
FREEZE
MUTE
ECO AUTO
ASPECT
CANCEL QUICK
MENU
ENTER
Q
1234
Finishing
1
Switch off the power of the connected equipment
2
Switch off the power of the projector
Main unit operation: Press the STANDBY button.
Remote control operation: Press the STANDBY button.
Warrning
Do not unplug the power cable while the STANDBY indicator is blinking amber. Doing so may shorten the life of the lamp
or damage the projector.
Power Off
OK
?
The [Power Off] display appears.
When the level gauge reaches maximum, the projection screen will go
off (in about 5 seconds) and the projector will enter the power-off op-
eration.
Note
* The operation can be cancelled by pressing a button other than the
STANDBY button.
* One more press of the STANDBY button will switch off the power.
3
Unplug the power cable
Check that the STANDBY indicator is lit in amber and then unplug the power cable.
The STANDBY indicator will go off when the power cable is unplugged.
Blinking amber
(Approximately 90 seconds)
Lit amber
Standby mode
The STANDBY indicator changes to blink-
ing amber and lights a steady amber after
about 90 seconds (when the unit enters the
standby mode).
