Technical Specifications

PH50CABPS-B
PELLET STOVE
O P P Q R S T U V W X T Y Y Z V T W [ S \
LARGE
4-1/2”
23-3/4”
23-3/16”
35-1/2”
9-1/2”
32-5/16”
4-1/16”
22-11/16”
DESCRIPTION
Carbon Steel & Welded Seams in Firebox
Steel Door Hinges (Against Cracking)
Component parts (Hopper, auger, burn-pot, baffle
plate, auger shaft, and fasteners) against cracking,
breakage, and welded seam separation.
Electrical Components
Accessory Items
Painted Surface of the stove
Glass (Thermal Breakage Only)
Labor/Installation/Construction
Transportation/Delivery
COVERAGE
5 Years
5 Years
5 Years
1 Year
1 Year
1 Year
1 Year
N/A
N/A
Hopper Capacity
BTU/h (input)
Efficiency with blower
BTU/h (output) with blower
(BTU/h x Efficiency)
Heating area
Burn time
Emissions
Air Wash System for cleaner glass
Ignition type
Feeding System
Thermostatic or Manual
Intensity Levels
Blower
Flue pipe diameter
Dimensions W x H x D
Stove weight / Shipping weight
Mobile home approved
Outside air kit
Made in
Approvals
120 lb
Up to 50,000
EPA Efficiency 80%
FRONT VIEW DIMENSIONS
SIDE VIEW DIMENSIONS
TOP VIEW
TO CALCULATE PIPE INSTALLATION
A
B
C
C
FLOOR PROTECTION &
CLEARANCES
CORNER INSTALLATION
MANUFACTURER’S WARRANTY (REFER TO MANUAL FOR DETAILS)
40,000
Up to 2,200 sq. ft.
Up to 70 hours
1.2 grams per hour
Yes
Automatic Thermostat Dial
Automatic Auger
Thermostatic
23 Levels
Included
3” or 4”
23-3/4” x 35-1/2” x 23-3/16”
179.8 lb / 258 lb
Yes
Included
China
USA and Canada
