Gigabit Ethernet Switch User's Manual

WGS3 Layer 3 Switch User’s Manual
- 49 -
High/Medium/
Low Priority
*2
6/4/2 WGS3-404 supports Quality of Service (QoS) by using four priority
queues (High, Medium, Low and Lowest), with Weighted Fair Queuing
for each port. Up to 8 separate traffic classes are defined in IEEE
802.1p. So any packets with a priority equal to or higher than High
Priority (default is 6) are placed in the high priority queue and so do
others. Any packets with a priority lower than Low Priority (default is
2) are placed in the lowest priority queue. You can use “4.5.4.1 VLAN
Port Configuration” to configure the default priority for each port.
Aging Time 300 Time-out period in seconds for aging out dynamically learned MAC
addresses information.
Range: 10 - 1000000 seconds
1: Only displayed on WGS3-2620.
2: Only displayed on WGS3-404
