WGS3 Layer 3 Switch User’s Manual
- 33 -
To add a new user, select <Add>. When you add a user, the following screen is displayed.
Parameter Description
User Name* Specifies a user authorized management access to the switch via the console,
Telnet or HTTP.
Password* Passwords can consist of up to 11 alphanumeric characters and are not case
sensitive.
Access Right ADMIN: Read/Write for all screens. GUEST: Read Only for all screens.
Console Access Authorizes management via the console.
Telnet Access Authorizes management via Telnet.
HTTP Access Authorizes management via HTTP (that is, Microsoft Internet Explorer 4.0 or later
version).
* These entries can consist of up to 15 alphanumeric characters and are not case sensitive.
