WGS3 Layer 3 Switch User’s Manual
- 22 -
4.4.1 Changing the Network Configuration
Use the Network Configuration menu to set the bootup option, configure the switch’ s Internet Protocol
(IP) parameters, or enable the on-board Web agent. The screen shown below is described in the
following table.
Parameter Description
IP Configuration* Screen used to set the bootup option, or configure the switch’s IP
parameters.
IP Connectivity Test (Ping) Screen used to test IP connectivity to a specified device.
HTTP Configuration Screen used to enable the Web agent.
* This menu does not appear on WGS3-404 or if the WGS3-2620 is set to multilayer mode. In this case,
you need to configure an IP interface for each VLAN that needs to connect to any device outside of its
own VLAN group. (See “Subnet Configuration”)
