WGS3 Layer 3 Switch User’s Manual
- 17 -
4.3 System Information Menu
Use the System Information Menu to display a basic description of the switch, including contact
information, and hardware/firmware versions.
Menu Description
System Information Provides basic system description, including contact information.
Switch Information Shows hardware/firmware version numbers, power status, and
expansion modules used in the switch.
