WGS3 Layer 3 Switch User’s Manual
- 216 -
VLAN The VLAN within which the gateway or destination address resides.
Next Hop The IP address of the router at the next hop.
Type The IP route type for the destination network. This switch supports the following
types:
Direct - A directly connected subnetwork.
Indirect - A remote IP subnetwork or host address.
Myself - A switch IP address on a specific IP subnetwork.
Bcast - A subnetwork broadcast address.
Mcast - An IP multicast address.
Invalid - A illegal IP address to be filtered.
Protocol The route was learned in one of the following ways:
Local - Manually configured
Mgmt. - Set via SNMP
ICMP - Obtained via ICMP redirect.
RIP - Learned via RIP protocol.
OSPF – Learned via OSPF protocol.
Other - Learned by some other method.
Route Tag* The route tag represents the device that originated this routing entry.
Route Aging* The number of seconds elapsed since this route was last updated or otherwise
determined to be correct. (This entry only applies to RIP.)
Routing Metric* A relative measure of the path cost from this switch to the destination network. (This
value depends on the specific routing protocol.)
*These three options is only for WGS3-2620.
