WGS3 Layer 3 Switch User’s Manual
- 209 -
Forward Delay The maximum time (in seconds) the root device will wait before changing states (i.e.,
listening to learning to forwarding).
Hold Time The minimum interval between the transmission of consecutive Configuration BPDUs.
Designated
Root
The priority and MAC address of the device in the Spanning Tree that this switch has
accepted as the root device.
Root Cost The path cost from the root port on this switch to the root device.
Root Port The number of the port on this switch that is closest to the root. This switch
communicates with the root device through this port. If there is no root port, then this
switch has been accepted as the root device of the Spanning Tree network.
Configuration
Changes
The number of times the Spanning Tree has been reconfigured.
Topology Up
Time
The time since the Spanning Tree was last reconfigured.
