WGS3 Layer 3 Switch User’s Manual
- 201 -
5.8 Monitoring the Switch
The Network Monitor Menu provides access to port statistics, address tables, STA information, VLANs
registration and forwarding information, multicast groups, and subnet addresses. Each of the screens
provided by these menus is described in the following sections.
Menu Description
Port Statistics Displays statistics on port traffic, including information from the Interfaces
Group, Ethernet-like MIB, and RMON MIB.
Layer 2 Address Table Contains the unicast address table.
Bridge Menu Displays Spanning Tree settings for the overall switch and for specific
ports.
VLAN Menu Displays ports dynamically learned through GMRP or GVRP, and ports
that are currently forwarding VLAN traffic.
IP Multicast Registration
Table
1
Displays all the multicast groups active on this switch, including the
multicast IP address and the corresponding VLANs.
IP Menu
2
Displays all the IP subnets used on this switch, as well as the
corresponding VLANs and ports. Also contains the ARP table, routing
table, and multicast menu.
*1: This menu is only displayed if WGS3-2620 is set to Layer 2 mode.
*2: This menu is only displayed on WGS3-404 or WGS3-2620 when it is set to multilayer mode.
.
